UL10368 300V XLPE Tinned Copper Stranded Electric Wires Cables
B&T (Zhangzhou) Cable Co., Ltd.- Application：General Use of Wiring
- Conductor Material：Plastic
- Cover Material：XLPE
- Type：Halogen Free
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：UL10368
- Wire Core Material：Copper
- Certification：ISO, RoHS, UL, Reach
- Model：UL10368
- Brand：Bort
- Color：White Blue Red Black Yellow
- Rated Voltage：300V
- UL Flame Test：UL Vm-1&CSA FT1
- Current：DC,AC
- Production Process：Welding
- Species：Terminal
- Character：Environmental Protection
- User：Socket Terminals
- Transport Package：Coil
- Specification：22AWG
- Trademark：BORT
- Origin：China
- HS Code：8544492900
- Production Capacity：500000km,Per Year
Description
AWGNO.of Cond Insulation Thick. Outside Thick. Packing No./mm mm mm m/r Ω/mm 30 7/0.1 0.25 0.80 1220 354.33 28 7/0.127 0.25 0.90 1220 223.75 26 7/0.16 0.25 1.00 1220 139.76 24 11/0.16 0.25 1.10 1220 88.36 22 17/0.16 0.25 1.30 610 60.16 20 21/0.178 0.25 1.50 610 38.58 18 34/0.178 0.25 1.70 610 22.98 16 26/0.254 0.25 2.00 610 15.06 28 1/0.320 0.25 0.85 1220 227.39 26 1/0.404 0.25 0.95 1220 142.79 24 1/0.511 0.25 1.05 1220 89.39 22 1/0.643 0.25 1.15 1220 54.30 20 1/0.813 0.25 1.35 610 33.90 18 1/1.024 0.25 1.55 610 21.40
