0.20 Stranded UTP CAT6 LAN Cable with Flexible

Hangzhou Risun Cable Co., Ltd.
  • Application：Local Communication Cable, LAN Cable
  • Conductor Material：Bc,Tc,Cu,CCA,CCS
  • Cover Material：PVC,PE,LSZH, Cm, Cmr
  • Type：Cat 6
  • Material Shape：Round Wire
  • Conductor Type：Stranded

Base Info

  • Model NO.：UTP CAT6
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, ISO, RoHS, UL, ETL SGS CPR
  • Brand：Risun or OEM
  • LAN Cable：Network Cable
  • Cores/Pairs：8,4
  • Separator：Filler
  • Transport Package：305m,Pull Box, 2boxes,CTN.
  • Specification：ETL, CE, RoHS, SGS, ISO9001
  • Trademark：RISUN or OEM
  • Origin：Hangzhou, Zhejiang, China(Mainland)
  • HS Code：8544491100
  • Production Capacity：20000 Boxes , Month

Description

ConstructionConductor24AWG Bare Copper  7/0.20 ±  0.01mmmInsulationHDPE 0.96 ± 0.02mmCores/Pairs8/4Sheath5.6+/-0.1mm PVC (FR,RoHS,UV)/ LSOH / PE
Mechanical Properties
ElongationMin. 300%
Temperature Range-20 up to +75° C
Tensile strengthMin. 1.68Kg/mm2

Electrical Properties (at 20°C)
Conductor ResistanceMax. 9.38 ohm/100m
Resistance UnbalanceMax. 2%
Insulation Resistance150 ohm/KM
Mutual CapacitanceMax. 5600pF/100m
Cpacitance UnbalanceMax. 330pF/100m
Impendance100+/-15 ohm
Spark Test2000V
Velocity Propagation67%


 		AttenuationRLNextPS Next
(MHz)(db/100m)(db)(db)(db/100m)
1MHz2.02065.363.5
4MHz4.12356.354.2
8MHz5.824.552.450.5
10MHz6.62551.349.2
16MHz8.22549.347.4
20MHz9.32548.846.9
25MHz10.42445.343.4
31.25MHz11.72343.041.8
62.5MHz17.02139.237.2
100MHz22.02036.334.4
155MHz28.11935.533.6
200MHz32.41931.829.9
240MHz36.01830.628.7
300MHz41.01829.227
350MHz44.91728.025.6
