Ce Certificated Aluminum Alloy XLPE Insulation Concentric Cable, Electric Wire, Electric Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Solid
- Application：Overhead, Heating, Underground
- Conductor Material：Copper
- Sheath Material：Polyolefine
- Insulation Material：XLPE
Base Info
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, CCC, RoHS, VDE
- Brand：Feiya
- Transport Package：Rolls or According to Customers′ Request
- Specification：Conductor nominal section mm2:0.75;1.0;1.5;2.5;4;6
- Trademark：Fengda
- Origin：Tianjin, China
- HS Code：8544421900
Description
Code NameTotal Area Stranding and Wire Diamete Overall Diameter Linear Mass Nominal Breaking Load Max.D.C. Resistance at 20°c AWG or MCM mm2 mm mm kg/km daN Ω/km Peachbell 6 13.29 7/1.554 4.67 37 249 2.1692 Rose 4 21.16 7/1.961 5.89 58 396 1.3624 Iris 2 33.61 7/2.474 7.42 93 597 0.8577 Pansy 1 42.39 7/2.776 8.33 117 732 0.6801 Poppy 1/0 53.48 7/3.119 9.36 147 873 0.539 Aster 2/0 67.42 7/3.503 10.51 186 1100 0.4276 Phlox 3/0 85.03 7/3.932 11.800 234 1347 0.339 Oxlip 4/0 107.23 7/4.417 13.26 296 1698 0.2688 Valerian 250 126.71 19/2.913 14.57 349 2062 0.2275 Sneezewort 250 126.71 7/4.80 14.4 349 2007 0.2275 Laurel 266.8 135.16 19/3.01 15.05 373 2200 0.2133 Daisy 266.8 135.16 7/4.96 14.9 373 2141 0.2133 Peony 300 152 19/3.193 15.97 419 2403 0.1896 Tulip 336.4 170.45 19/3.381 16.91 470 2695 0.1691
