PVC H05vvf Aluminium Copper Core Epr Insulated Thermoplastic Elastomer Sheathed Cold Industrial Twisted Resistant Wind Power Flexible Cable

Tianjin Feiya Electric Wire & Cable Co., Ltd.
  • Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Home Wire
  • Voltage：Low and Medium Voltage Cable
  • Insulation Material：Epr,XLPE,PVC,Nr+SBR
  • Sheath Material：Epr,XLPE,PVC
  • Material Shape：Flat , Round
  • Wire Core Material：Class 5 Flexible Copper Conductor

Base Info

  • Model NO.：Power Cables
  • Certification：ISO, CCC, CE
  • Model：H05gg-F
  • Brand：Feng Da
  • Colour：Red,Green,Blue,Black,White,as Request
  • OEM/ODM：Yes
  • Flame Test：Yes
  • Transport Package：Rolls or According to Customer′s Request
  • Trademark：feiya
  • Origin：Tianjin, China

Description

0.6/1kVCopper core ethylene propylene rubber insulated silicon rubber sheath cold resistant twisted resistant flexible cable for wind power generationFDEG-55Copper core ethylene propylene rubber insulated silicon rubber sheath severe cold resistant twisted resistant flexible cable for wind power generation
 Spec. and sizeFDEF-25
FDEF-40
FDES-25
FDES-40
FDES-55
FDGG-40
FDGG-55
FDEG-40
FDEG-55
FDEH-25
FDEH-40
FDEH-5511.5 ~ 40021.0 ~ 3531.0 ~ 30041.0 ~ 30051.0 ~ 3003+14 ~ 3006~361.5 ~ 4
Technical Performance

1.The conductor shall comply with the requirements of fifth kinds of soft round stranded conductors specified in GB/T 3956-2008
2.The highest operating temperature of Conductor: ethylene propylene rubber insulation 70ºC, 90ºC; silicone rubber insulation 90ºC.
3.The finished cable shall be to withstand the normal temperature torsion test and the low temperature torsion test specified in Appendix B of GB/T 29631-2013.
4.The finished cable shall be able to withstand weight test as specified in Appendix C of GB/T 29631-2013.
5.The finished cable shall be able to withstand the low temperature bending test specified in Appendix D of GB/T 29631-2013.
