• Model NO.：NYCYRY, N2XCYRY, NYSYRY, N2XSYRY, NYCYBY, N2XC
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, CE, CCC, SGS
• Brand：Hongda
• Standard：IEC 60332, 1, IEC 60502-1, CE, RoHS
• Rated Voltage：0.6,1 Kv
• Transport Package：Drum or as Customer Require
• Specification：0.5mm2 to 10mm2
• Trademark：Hongda
• Origin：China
• HS Code：8544492100
• Production Capacity：400km,Month

Basic Info.

Model NO. NYCYRY, N2XCYRY, NYSYRY, N2XSYRY, NYCYBY, N2XC Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, CE, CCC, SGS Brand Hongda Standard IEC 60332, 1, IEC 60502-1, CE, RoHS Rated Voltage 0.6/1 Kv Transport Package Drum or as Customer Require Specification 0.5mm2 to 10mm2 Trademark Hongda Origin China HS Code 8544492100 Production Capacity 400km/Month

Product Description

Shielded & Armoured Control cables

NYCYRY , N2XCYRY , NYSYRY , N2XSYRY, NYCYBY , N2XCYBY , NYSYBY , N2XSYBY


Technical Specification

• In the voltage designation of U₀/U(U_m),The rated voltages of the cables considered in IEC standard are as follows: U₀/U(U_m)=300/500(600) V - 0.6/1(1.2) KV.
  U₀ is the rated power frequency voltage between conductor and earth or metallic screen.
  U is the rated power frequency voltage between conductors.
  U_m is the maximum value of the "highest system voltage" for which the equipment may be used.
  Construction features:
  -Conductor size : Up to 10 sq.mm
  - No. of cores : 2 to 61 cores
  -Conductor material: Plain/Tinned copper
  -Conductor type: (Class1)/Stranded(class2)/Fine stranded (Class 5) - Round
  -Insulation: Cross-linked polyethylene (XLPE) or Polyvinyl chloride ( PVC)
  -Filler/Inner sheath: Polyvinyl chloride (PVC)
  -Metallic sheath : Lead sheath
  -Separation sheath: Polyvinyl chloride (PVC) or polyethylene ( PE)
  -Armour: Galvanized steel wire , tape or braided armour
  -Sheath: Polyvinyl chloride (PVC) or high density polyethylene ( HDPE)
  Other futures :
  -Ultra violet (UV) resistant colored outer sheath
  -Low smoke and fume (LSF)
  -Halogen free and flame retardant (HFFR)
  - Oil & hydrocarbon resistant
  -Fire resistant
  -Vermin proof
  Standards : IEC60502-1 , VDE0250 , IEC60227 , PAS 5308 , BS6500 , ISIRI3569-2 , ISIRI607(53)



Cores x  Section Area	Insulation  Thickness	Jacket  Thickness	Maximum  resistance at 20ºC	Cable  Diameter	Copper  approx. weight	Cable Approx.  Weight	Packing Length
mm2	mm	mm	Ω/km	mm	kg/km	kg/km	m
7 x 1	0.6	1.2	18.10	13.00	115	270	2750
12 x 1	0.6	1.2	18.10	15.50	175	400	2500
19 x 1	0.6	1.2	18.10	17.50	248	520	1750
2 x 1.5	0.7	1.2	12.10	11.00	70	190	2000
3 x 1.5	0.7	1.2	12.10	11.50	86	210	2000
4 x 1.5	0.7	1.2	12.10	12.50	110	250	2000
5 x 1.5	0.7	1.2	12.10	13.50	125	280	2000
7 x 1.5	0.7	1.2	12.10	4.50	153	340	2000
12 x 1.5	0.7	1.2	12.10	17.50	239	510	1750
14 x 1.5	0.7	1.4	12.10	18.50	297	560	1750
19 x 1.5	0.7	1.4	12.10	21.00	347	720	1250
24 x 1.5	0.7	1.4	12.10	24.00	432	1000	1000
27 x 1.5	0.7	1.4	12.10	24.50	477	1000	750
37 x 1.5	0.7	1.4	12.10	27.50	622	1250	750
48 x 1.5	0.7	1.6	12.10	31.50	750	1600	500
2 x 2.5	0.7	1.2	7.41	12.00	93	220	1500
3 x 2.5	0.7	1.2	7.41	12.50	119	260	1500
4 x 2.5	0.7	1.2	7.41	13.50	146	310	1500
5 x 2.5	0.7	1.2	7.41	14.50	173	350	1500
7 x 2.5	0.7	1.2	7.41	15.50	223	420	1500
12 x 2.5	0.7	1.4	7.41	20.00	358	680	1500
19 x 2.5	0.7	1.4	7.41	22.50	529	930	1000
24 x 2.5	0.7	1.4	7.41	26.50	663	1310	750
27 x 2.5	0.7	1.4	7.41	27.00	680	1400	750
2 x 4	0.7	1.2	4.61	13.50	125	290	1000
3 x 4	0.7	1.2	4.61	14.00	165	330	1000
4 x 4	0.7	1.2	4.61	15.00	206	400	1000
5 x 4	0.7	1.2	4.61	16.00	247	460	1000
7 x 4	0.7	1.2	4.61	17.50	325	560	1000
12 x 4	0.7	1.4	4.61	22.50	530	920	1000
2 x 6	0.7	1.2	3.08	14.50	167	350	1500
3 x 6	0.7	1.2	3.08	15.00	210	410	1500
4 x 6	0.7	1.2	3.08	16.00	285	500	1500
5 x 6	0.7	1.2	3.08	17.50	345	590	1500
7 x 6	0.7	1.4	3.08	18.20	430	719	1500
3 x 10	0.8	1.2	1.83	17.50	345	580	1000
3 x 10	0.8	1.4	1.83	18.50	441	710	1000
4 x 10	0.8	1.4	1.83	20.50	540	870	750
5 x 16	0.8	1.4	1.15	20.00	520	830	1500
4 x 16	0.8	1.4	1.15	21.50	671	1020	750
5 x 16	0.8	1.4	1.15	23.50	825	1230	750



Packing & Shipping:

Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.

Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping Port:
Shanghai, Qingdao, Tianjin or other ports as per your requirements.

Sea freight:
FOB/C&F/CIF/DAP quotation are all available.
