Almelec Cable 34.4mm2
YIFANG ELECTRIC GROUP INC.- Type：Bare
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Al Alloy
- Material Shape：Round Wire
- Certification：ISO9001, CE, CCC
Base Info
- Model NO.：B2-59 Almelec cable 34.4mm2
- Brand：Yifang Cable
- Transport Package：Drum
- Specification：Almelec cable 34.4mm2
- Trademark：yifang cable
- Origin：China
- Production Capacity：500, 000 Kilometers Per Month
Description
Basic Info.
Model NO. B2-59 Almelec cable 34.4mm2 Brand Yifang Cable Transport Package Drum Specification Almelec cable 34.4mm2 Trademark yifang cable Origin China Production Capacity 500, 000 Kilometers Per MonthProduct Description
| 1.1 | Type Model No | ‐ | Almelec 34.4mm2 |
| 1.2 | Country of origin | ‐ | China |
| 2 | Structure | ‐ | |
| 2.1 | nominal section | mm² | 34,4 |
| 2.2 | Number | no. | 7 |
| 2.3 | Nominal diameter Diameter of single wire | mm | 2, 5 |
| 2.4 | Conductor diameter | mm | 7,5 |
| 3 | MECHANICAL PROPERTIES AND ELECTRICAL | ||
| 3.1 | Mass per unit length of the cable | Kg/Km | 93 |
| 3.2 | Breaking load | daN | 1105 |
| 3.3 | Modulus of elasticity | Hbar | 6000 |
| 3.4 | Resistance at 20 ° C | Ohm/km | 0,958 |
| 4 | Standards | NFC 34-125 IEC 61089 |
