21years Professional Manufacture Produce RG6 Rg59 Coax Coaxial Cable with ETL RoHS CE (RG6)
Hangzhou Xingfa Technology Co., Ltd.- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
Base Info
- Model NO.：RG6
- Type：Coaxial Cable
- Material Shape：Round Wire
- Conductor Type：Solid
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, UL, Reach ETL
- Model：RG6 Coaxial Cable
- Item：RG6 Coaxial Cable
- Package Length：100m, 305m, 500m...
- Inner Conductor：CCS, Cu etc.
- Conductor Od：1.02mm
- Insulation：4.57mm
- Shiled：Aluminum Foil
- Braiding Material：Al, CCA, Cu, Tcu etc.
- Braiding Coverage：30%, 45%, 60%, 80%, 90% etc.
- Jakcet：6.9mm PVC
- Jakcet Color：White, Black, Yellow etc.
- Transport Package：100m,Roll, 200m,Roll, 305m,Roll, Wooden Plastic
- Specification：ISO CE RoHS SGS REACH BV
- Trademark：ZHONGLI
- Origin：Hangzhou, China
- HS Code：8544491100
- Production Capacity：18000 Kilometer,Month
- Package size per unit product：57.00cm * 29.00cm * 25.50cm
- Gross weight per unit product：38.000kg
Description
[@68o F. (20o C.)]
Frequency (MHz)
Maximum (dB/100 ft.)
Maximum (dB/100 m)
5
0.58
1.9
50
1.5
4.9
100
2.0
6.5
200
2.8
9.2
400
4.1
13.6
700
5.6
18.4
900
6.2
20.3
1000
6.5
21.4
1450
8.0
26.2
1800
8.5
27.9
2100
9.5
31.1
2250
10.0
34.0
3000
11.4
37.5
Examples:
1) RG6 Coaxial Cable 75ohm Dual / Standard shield
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+6.90±0.05mm PVC Jacket
2) RG6 Coaxial Cable 75ohm Tri Shielded
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+Al Foil+6.9mm PVC Jacket
3) RG6 Coaxial Cable 75ohm Quad Shield
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid +Double Al Foil+ Al Wire braiding +7.5mm PVC Jacket
4) RG6 Coaxial Cable 75ohm With Messenger
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+6.90±0.05mm PVC Jacket+1.30+0.05mm Messenger
5)OEM
