FTTH G657A GJYXFCH GJXFH Fiber Optic Drop Cable Patch Cord
HNK Optic Equipment Co., LIMITED- Application：Communication
- Type：Single-mode Fiber
- Connection Structure：Sc or FC
- Certification：RoHS, UL, CE, ISO9001
- Brand：HNK or OEM
- Sheath Material：PE, LSZH, PVC
Base Info
- Model NO.：GJYXFCH or GJXFH
- Fiber Type：G657A or G652D
- Fiber Count：1~2
- Connector Type：Sc,FC PC,APC
- Cable Type：GJXFH or GJYXFCH
- Length：According to Requirement
- Transport Package：Wooden Reel
- Specification：RoHS
- Trademark：HNK or OEM
- Origin：Shenzhen, China
- HS Code：85447000
- Production Capacity：10000km,Month
Description
SPECIFICATIONSGJYXFCH GJXFH Tension Term(Long Term) N 300 40 Tension Term(Short Term) N 600 80 Crush Term(Long Term) N/100mm 1000 500 Crush Term(Short Term) N/100mm 2200 1000 Min. Bend Radius(Dynamic) mm 30D 20D Min. Bend Radius(Static) mm 15D 10D
Ordering Information
Using the available configurations amend/create product codes using the formula below.
Part Number: DPC-AA-BB-CDEFGCL
Ordering Guide
Ordering Sample
Ordering Information
Using the available configurations amend/create product codes using the formula below.
Part Number: DPC-AA-BB-CDEFGCL
Ordering Guide
| AA | BB | C | D | E | F | G | CL |
| Connector Type | Connector Type | Fiber Type | Fiber Count | Cable Type | Length | Jacket Materia | Jacket Color(CL) |
| FP,SP,SA | FP,SP,SA | G652D =9/125 G652D G657A =9/125 G657A | SX=Simplex DX=Duplex | FH=GJXFH CH=GJYXFCH | 0015=1.5M 0200=20M | 1=LSZH 2=PE | As noted in Color code chart |
Connector Type Code
| Code | Connector | Code | Connector | Code | Connector | Code | Connector |
| FP | FC/PC | FA | FC/APC | LP | LC/PC | LA | LC/APC |
| SP | SC/PC | SA | SC/APC | TP | ST/PC | TA | ST/APC |
| MU | MU | MT | MTRJ | DN | DIN | E2 | E2000 |
Ordering Sample
Part Number | Description |
DPC-SP-FP-G657ASXFH10002WH | SC/PC-FC/PC Drop Cable Patch Cord, Singlemode G657A, |
