• Wire Core Material：Copper Wire
• Certification：CE, ISO, RoHS, CCC, UL, VDE
• Model：Coaxial Cable Assembly
• Brand：Roho
• Frequency Range：Flexible Cables DC 11GHz, Semi-Rigd Cables DC18GHz
• Withstand Voltage：≥2500V,50Hz
• Working Voltage：≤1000V,50Hz (Sea Level)
• Insulation Resistance：≥5000m Ohm
• RF Leakage(2-3GHz)：Flexible: ≥90dB
• 3rd Order Intermodulation：≥140dbc
• Body：Brass--Au Plated , Ternary Alloy Plating
• Pin Contacts：Brass,Beryllium Copper--Au Plating
• Transport Package：Foam + Carton
• Origin：China
• Production Capacity：100000,Month

Frequency RangeFlexible cables DC 11GHz, semi-rigd cables DC18GHzWithstand Voltage ≥2500V,50Hz Working Voltage≤1000V,50Hz (sea level)Insulation Resistance≥5000mΩContact ResistanceInner conductor: ≤1.0mΩOuter conductor: ≤0.2mΩRF leakage(2-3GHZ)Flexible: ≥90dB3rd order  intermodulation≥140dBcMECHANICAL DATA Coupling nut torqueRecommended: 68Ncm--123Ncm / 6.0 in. lbs--10 in.lbs Proof torque: 170 Ncm / 15.0 in.lbsProof torque170Ncm / 15.0 in.lbsDurability (matings)≥500ENVIRONMENTAL DATA Temperature range-65°C  to +165°C MATERIAL DATA BodiesBrass--Ternary alloy plating Pin contactsBrass--Au/Ag platingSocket contactsCopper beryllium alloy--Au platingCrimp ferrulesBrass-- ternary alloy plating InsulatorPTFEGasketsSilicone rubber
