Coaxial Cable CCTV Cable Rg58 Cable Rg59 with Power RG6 Cable Data Cable CATV Cable 75ohm Communication Cable Data Cable TV Cable
SUNMECH INDUSTRY CO., LTD.- Type：Insulated
- Conductor Type：Fomed,Solid
- Application：Overhead, Indoor
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PE
Base Info
- Model NO.：RG58,RG59,RG6,RG11,KX6,RG58+2C,RG59+2C,RG6+2C
- Material Shape：Round Wire
- Range of Application：LSOH
- Certification：ISO9001, CE, UL, RoHS
- Brand：Sunmech
- Coaxial Cable：CCTV,RG6
- Transport Package：Wooden Reel,Plastic Reel,Paper Spool
- Specification：100M,200M,300M
- Trademark：SUNMECH
- Origin：China
- HS Code：8544200000
Description
STANDARD SHIELD
TRI-SHIELD
QUAD-SHIELD
CONDUCTOR
MATERIAL
BC/CCS
BC/CCS
BC/CCS
Nom.Dia.
18AWG
18AWG
18AWG
DIELECTRIC
MATERIAL
Foam PE
Foam PE
Foam PE
Nom.Dia.
4.57mm
4.57mm
4.57mm
SHIELD
MATERIAL
Al Foil+Al Braiding
Al Foil+Al Braiding+Al Foil
(Al Foil+Al Braiding)*2
COVERAGE
40%-95%
40%-95%
40%-60%
JACKET
MATERIAL
PVC/PE
PVC/PE
PVC/PE
Nom.Thick.
0.80mm
0.80mm
0.86mm
Nom.Dia.
6.91mm
7.06mm
7.62mm
MESSENGER
MATERIAL
Galvanized steel wire
Nom.Dia.
1.30mm
1.30mm
1.30mm
Nominal Impedance(ohm)
75±3
Nominal Velocity of propagation(%)
85
Nominal Capacitance(pf/m)
50
Spark Test(VAC)
3000
SRL(dB)
20
20
Attenuation
[68°F(20ºC)]
Frequency(MHz)
Maximum(dB/100ft)
Maximum(dB/100m)
5
0.58
1.9
55
1.6
5.25
187
2.85
9.35
300
3.55
11.64
450
4.4
14.43
600
5.1
16.73
750
5.65
18.54
865
6.1
20.01
1000
6.55
21.49
