• Model NO.：RG6
• Specification：100,200,300,500M
• Trademark：TUOXUN
• Origin：China
• HS Code：85442000
• Production Capacity：3000km,Month

General description of Foam PE Network Coaxial Cable
  1.Inner Conductor: 0.5mm/0.643mm/0.81mm/1.02mm BC/CCA/CCS
  2.Dielectric: FPEΦ4.57mm
  3.Shield: AL/P foil + ALΦ0.12mm×96P/128P braiding
  4.Jacket:PVCΦ6.91mm

Application:
1) CATV-community antenna television
2) CCTV-closed-circuit television
3) DBS-direct broadcasting satellite
4) Multiplex telephony
5) Closed-circuit television surveillance system & radio vision system
6) Electronic warfare, aviation and other electronic devices

 Procuct Construction

STANDARD SHIELD

TRI-SHIELD

QUAD-SHIELD

CONDUCTOR

MATERIAL

BC/CCS

BC/CCS

BC/CCS

Nom.Dia.

18AWG

18AWG

18AWG

DIELECTRIC

MATERIAL

Foam PE

Foam PE

Foam PE

Nom.Dia.

4.57mm

4.57mm

4.57mm

SHIELD

MATERIAL

Al Foil+Al Braiding

Al Foil+Al Braiding+Al Foil

(Al Foil+Al Braiding)*2

COVERAGE

40%-95%

40%-95%

40%-60%

JACKET

MATERIAL

PVC/PE

PVC/PE

PVC/PE

Nom.Thick.

0.80mm

0.80mm

0.86mm

MESSENGER

MATERIAL

Galvanized steel wire

Nom.Dia.

1.30mm

1.30mm

1.30mm

Nominal Impedance(ohm)

75±3

Nominal Velocity of propagation(%)

85

Nominal Capacitance(pf/m)

50

Spark Test(VAC)

3000

SRL(dB)

20

20

Attenuation

[68°F(20ºC)]

Frequency(MHz)

Maximum(dB/100ft)

Maximum(dB/100m)

5

0.58

1.9

55

1.6

5.25

187

2.85

9.35

300

3.55

11.64

450

4.4

14.43

600

5.1

16.73

750

5.65

18.54

865

6.1

20.01

1000

6.55

21.49

FAQ

Q1. What kind of products can your company supply?
 A: We specialize in supplying network cable, coaxial cable, HDMI cable, VGA cable, telephone cable, speaker cable and etc.

Q2. What's your MOQ?
A: The MOQ of long meter cable is 50 km, or we can negociate.

Q3. What's your delivery time?
A: Our delivery time is about 15-20 days after comfriming the deposite, it is based on the quantity of the order.

Q4. What are your payment terms?
A: Normally, we accept T/T in advance, as for other payment term, we can negociate with you.

Q5. What's your trade term ?
A: We can accept FOB, CIF, EXW term.

Q6.  What kind of certifications do you have?
A: successively passed China's national compulsory product certification (i.e. CCC certification), national industrial product production license for wire and cable, ISO9001 (2008) quality management certification, CQC certification, UL product certification, CE product certification, National Radio and television equipment network certification, Certificate of adopting international standard product mark approved and issued by National Standardization Administration Committee..

Q7. Can your factory customize cables based on clients' samples or data sheet ?
 A: Yes, we can.
