RG174 Coaxial Jumper Cable with SMA/N/Fakra Connectors for Car Antenna
Otto Cable Technology Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, RF Cable, Car Antenna
- Conductor Material：BC,TC
- Cover Material：PVC
- Type：RG174
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：RG174
- Wire Core Material：TC,BC
- Certification：CE, ISO, RoHS
- Model：RG174
- Brand：Otto Cable
- Transport Package：Pallet; Carton; Coil
- Specification：2.8mm
- Trademark：OTTO CABLE
- Origin：China
- HS Code：854420
- Production Capacity：1000PCS,Day
Description
Basic Info.
Model NO. RG174 Wire Core Material TC/BC Certification CE, ISO, RoHS Model RG174 Brand Otto Cable Transport Package Pallet; Carton; Coil Specification 2.8mm Trademark OTTO CABLE Origin China HS Code 854420 Production Capacity 1000PCS/DayProduct Description
RG174 Coaxial Jumper Cable with SMA/N/Fakra Connectors for Car Antenna
Application:
• Car Antenna
• GPS, GSM
• Signal transmission
Features:
• 50 Ohm
• High temperature resistant upto 105ºC
• Good eletrical and welding performance provided by special insulation material.
• Smaller size, soft and handable
• Attenuation @1575 MHz: 1.1dB/M.
• REACH/RoHS compliant, CE certified.
• OEM/ODM
Assemblies:
• SMA, SMB, FAKRA,BNC, MCX, ......
• Customized Cable length / jacket color/ roll size/ packing
• Various colors of Heat shrinkable tube
Construction
| Item | Material | Diameter(mm) |
| Inner Conductor Dielectric Shield Jacket | Bare Copper / Tinned Copper Solid PE / XLPE Bare Copper or Tinned Copper Wire Braid PVC | 7*0.16 1.52 1.90 2.80 |
Electrical Characteristics
| Impedance (Ω) Capacitance (pF/m) Velocity of Propagation (%) Return Loss Installation Temp(ºC) Operating Temp(ºC) | 50±3 101 66 20 -30 to +85 / 105 -30 to +85 / 105 |
Attenuation (@20ºC)
| Frequency(MHz) | Max Attenuation(dB/m) |
| 400 600 860 1000 1575 | 0.62 0.72 0.90 1.00 1.10 |
