• Model NO.：WDZA-H
• Wire Core Material：None
• Certification：ISO, RoHS
• Model：Wdz-H
• Brand：Jsxd
• Original Tensile Strength：13 MPa
• Original Breakage Elongation：165 %
• pH：5.3
• Oxygen Index：40 %
• Conductivity：0.6 Us,mm
• Flame-Retardant Level：IEC 60332-3-22
• Transport Package：Aluminum Foil Bag Inside and Kraft Bag Outside
• Specification：25 kg
• Trademark：JSXD
• Origin：China
• HS Code：3901909000
• Production Capacity：8000 Ton Per Month

Basic Info.

Model NO. WDZA-H Wire Core Material None Certification ISO, RoHS Model Wdz-H Brand Jsxd Original Tensile Strength 13 MPa Original Breakage Elongation 165 % pH 5.3 Oxygen Index 40 % Conductivity 0.6 Us/mm Flame-Retardant Level IEC 60332-3-22 Transport Package Aluminum Foil Bag Inside and Kraft Bag Outside Specification 25 kg Trademark JSXD Origin China HS Code 3901909000 Production Capacity 8000 Ton Per Month

Product Description

WDZA-H Power Cable Sheath Material Low Smoke Halogen Free Flame Retardant


Description:



This series of products are suitable for medium and low voltage cables in rail transit, the product has good flame retardant, low smoke, no halogen acid gas release, is the first choice for environmental protection and safety cable material.

Processing:



This series of products, it is recommended to dry for about 2 hours before processing, drying temperature: 70ºC, drying temperature can rise to 80ºC in the starting state. It is recommended that the aspect ratio is about 25, and the screw with good plasticization is processed. The processing temperature is suggested to be:135ºC-140ºC-145ºC-150ºC-155ºC-160ºC(reference temperature).

Packing:



Net weight 25kg: Inner aluminum foil/polyethylene composite film bag, outer kraft paper composite bag.

Net weight 1000kg: Inner aluminum foil/polyethylene composite film bag, outer polypropylene woven composite bag.

Storage:

The product should be stored in a clean, dry and ventilated warehouse, and should not be damaged by sun, rain, water and other abnormal conditions.  Storage temperature should not be lower than 0ºC.  The storage period of the product shall not exceed 6 months from the date of production.
