• Model NO.：FTTH
• Fiber Cores：1-4 Cores
• Sheath Color：Black
• Outer Sheath：LSZH
• Transport Package：Wooden Drum
• Specification：Customized
• Trademark：Customized
• Origin：China
• HS Code：8544700000
• Production Capacity：500km,Day

         Items DescriptionNumber of fiber4 coresFiber typeG657AStrength membermaterialGalvanized steel wire/FRP/KFRPdiameter2*(0.5~0.8)mmOuter sheathmaterialLSZHdiameter1.8±0.2mmCable size (Height * width)4.0(±0.2) mm ×2.0 (±0.2)mmCable sheath thicknessMax. 0.8mm/Min. 0.4mmCable weight10KG±1KG
 Standard color of fiber and tube
The color of the individual fibers, shall be in accordance with  the table as below:Standard Colour IdentificationNo.1234ColorBlueOrangeGreenBrownOut sheath is black.

 Cable Mechanical characteristic
 ItemsDescriptionInstallation Temperature range  -20--+60ºCOperation and transport temperature-40-+70ºCMin Bending Radius(mm)Long term10Dshort term20DAllowable Tensile Strength(N)Long term40short term80Crush Load (N/100mm)Long term500short term1000

8.  Requirement for Order:
Fiber sort: Single mode G652,G655,G657, Multi mode 50/125,62.5/125,OM3,OM4.
Fiber brand: YOFC, Corning, Fiberhome OFS etc.
3.Sheath material: PE,LSZH, PVC( can be required).
4.Sheath color: Black ,can be required.
5.The fiber and tube color: according to stranded color, can be required.
6.The cable Size: shall be in accordance with the table, can be required.
7.Length of cable: generally is 2KM, can be required.
8.Other requirement:can be negotiated.





9.  Fiber characteristicFiber styleUnitSM
G652DSM
G657A1SM
G657A2conditionnm1310/15501310/15501310/1550attenuationdB/km≤0.36/0.23≤0.35/0.21≤0.35/0.21Dispersion1310nmPs/(nm*km)≤18≤18≤181550nmPs/(nm*km)≤22≤22≤22Zero dispersion wavelengthnm1312±101312±101300-1324Zero dispersion slopeps/(nm²×Km)≤0.091≤0.090≤0.092PMD Maximum Individual Fiber[ps/√km]≤0.2≤0.2≤0.2PMD Design Link Valueps/(nm²×Km)≤0.08≤0.08≤0.08Fiber cutoff wavelength λcnm>=1180,≤1330>=1180,≤1330>=1180,≤1330Cable cutoff wavelength λccnm≤1260..........MFD1310nmum9.2±0.49.0±0.49.8±0.41550nmum10.4±0.810.1±0.59.8±0.5Step(mean of bidirectional measurement)dB≤0.05≤0.05≤0.05Irregularities over fiber length and point discontinuitydB≤0.05≤0.05≤0.05Difference backscatter coefficientdB/km≤0.03≤0.03≤0.03Attenuation uniformitydB/km≤0.01≤0.01≤0.01Cladding diameterum125.0±0.1124.8±0.1124.8±0.1Cladding non-circularity%≤1.0≤0.7≤0.7Coating diameterum242±7242±7242±7Coating/chaffinch concentrically errorum≤12.0≤12.0≤12.0Coating non circularity%≤6.0≤6.0≤6.0Core/cladding concentricity errorum≤0.6≤0.5≤0.5Curl(radius)um≥4≥4≥4 G657A1  fiber Environmental Characteristics   (1310nm, 1500nm, &1625nm)Temperature dependence Induced attenuation at-60ºC to +85ºC≤0.05[db/Km]Temperature-humidity cycling
Induced attenuation at -10ºC to +85ºC,
 98% RH≤0.05[db/Km]Watersoak dependence Induced attenuation at 23ºC for 30 days≤0.05[db/Km]Damp heat dependence
Induced attenuation at 85ºC and 85% RH≤0.05[db/Km] for 30 daysDry heat aging at 85ºC ≤0.05[db/Km]Mechanical SpecificationProof  test                                   off  line>=9.0  [N]    >=1.0[%]  >=100[kpsi]Macro-bend induced attenuation100 turns around a mandrel of 50 mm dimeter   10 turns around a mandrel of 30 mm dimeter1550nm≤0.1[dB]10 turns around a mandrel of 30 mm dimeter1625nm≤0.3[dB]1 turn around a mandrel of 20 mm diameter1550nm≤0.1[dB]1 turn around a mandrel of 20 mm diameter1625nm≤0.5[dB]Coating strip forcetypical average force1.7[N]peak force>=1.3 ≤8.9[N]Daynamic stress corrosition susceptibility parameter nd(typical)>=20
 G657A2 fier Environmental Characteristics   (1310nm, 1500nm, &1625nm)Temperature dependence Induced attenuation at-60ºC to +85ºC≤0.05[db/Km]Temperature-humidity cycling
Induced attenuation at -10ºC to +85ºC,
 98% RH≤0.05[db/Km]Watersoak dependence Induced attenuation at 23ºC for 30 days≤0.05[db/Km]Damp heat dependence
Induced attenuation at 85ºC and 85% RH≤0.05[db/Km] for 30 daysDry heat aging at 85ºC ≤0.05[db/Km]Mechanical SpecificationProof  test                                   off  line>=9.0  [N]    >=1.0[%]  >=100[kpsi]Macro-bend induced attenuation10 turns around a mandrel of 30 mm dimeter1550mm≤0.3[dB]10 turns around a mandrel of 30 mm dimeter1625mm≤0.1[dB]1 turns around a mandrel of 20 mm dimeter1550nm≤0.1[dB]1 turns around a mandrel of 20 mm dimeter1625nm≤0.2[dB]1 turn around a mandrel of 15 mm diameter1550nm≤0.5[dB]1 turn around a mandrel of 15 mm diameter1625nm≤1.0[dB]Coating strip forcetypical average force1.7[N]peak force>=1.3 ≤8.9[N]Daynamic stress corrosition susceptibility parameter nd(typical)>=20
10.  Cable marking

The cable sheath shall be marked with white characters at intervals of one meter with following information:
Purchaser's name
Fiber type and counts
Cable type
Name of manufacturer
Country of origin
6.  Length marking
Notice: cable mark is available if requested by customer.

Packing Information
Packing material: Wooden drum+ Carton box
Packing length: standard length of cable shall be 2 km. Other cable length is also available if required by customer

12.  Our certificates :
1) ISO9002
2) SGS, ROHS
3) ULE329066
4) REACH

 Testing Lab:

No	Device name	No	Device name
1	Optical time domain reflectometer (OTDR)	8	GNZV Cable Torsion Testing Machine
2	Fiber Polarization Mode Dispersion	9	GQNV Cable Flexing Testing Machine
3	Fiber Dispersion ,Strain Tester	10	GJRV Cable Winding Testing  Machine
4	High Low Temperature Test Chamber	11	GZDV Cable Vibration Testing Machine
5	Cable Impact Testing Machine	2	Cable Water Penetration Test
6	Cable Squash Tensile Testing Machine		Fusion Splicer
7	GWQV Cable Bending Tester	14	Cable Water Penetration Test Rig


Fiber Optic Cable Mechanical Performance Testing Laboratory

Main Testing Type: Precision Test and Mechanical Test.
Precision Testing Machine: EXFO OTDR, EG&G PMD-440,CD-400.
Mechanical Performance Testing : Temperature, Impact, Tensile, Bending, Torsion, Flexing, Winding, Vibration, Water Penetration, Fusion Splicer, Water Penetration.



 Our advantages:
 Professional cable manufacturer.
About 10 years experiences in cable industry.
MOQ just 1Km.
ISO, UL , ROSH,REACH...certifications.
Can be customized production of fiber optic cable.
Independent Lab with full set of testing machines.
We have export license ,can support cable to you without profit, because we can get tax refund from Chinese government. Tag: FTTH drop wire
