Grounding Copper PVC Insulated Yg Ecc Cable Electrical Wire
People's Cable Group Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground, Building
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：Wire Cable
- Material Shape：Round Wire
- Range of Application：LSOH
- Certification：ISO9001, CE, CCC, RoHS, BV
- Brand：Rmjt
- Voltage：300-1000V
- Structure：Stranded Copper
- OEM or ODM：Yes
- Usage：Electircal Transimision
- Size：1.5-240sq.mm
- Transport Package：Coils
- Specification：H07V-R H07V-U, H05V-R H05V-U
- Trademark：RMJT
- Origin：China
- HS Code：8544492100
- Production Capacity：1000000000000000meters,Year
Description
Oxygen cabin wires often use BV, BX, RV, RVV series wires.BV copper core PVC insulated wire, long-term allowable temperature 65 ºC, minimum temperature -15 ºC, working voltage AC 500V, DC 1000V, fixed laying indoors or outdoors, can be exposed or concealed. BX copper-cored rubber insulated wire, with a maximum operating temperature of 65 ºC, applied indoors. RV Polyvinyl chloride insulated single-core flexible cord, the highest use temperature is 65 ºC, the lowest use temperature is -15 ºC, the working voltage is AC 250V, DC 500V, used as the internal wiring of instruments and equipment RVV copper core PVC insulated and sheathed flexible wire, allowing long-term working temperature of 105 ºC, working voltage of AC 500V, DC 1000V, used for humid, high mechanical protection requirements, often moving and bending occasions. Conductor No/Dia. Mm Nominal Insulated thick mm Max overall Dia. Mm Condcutor Resistance at 20 Min insulated resistance at 70MΩ/km Weight
Kg/km Cu Al Cu Al 1.5 1/1.38 0.7 3.3 12.1 - 0.011 19.2 - 1.5 7/0.52 0.7 3.5 12.1 - 0.01 20.6 - 2.5 1/1.78 0.8 3.9 7.41 11.8 0.01 30.8 15 4 1/2.25 0.8 4.4 4.61 7.39 0.0085 45.5 21 6 1/2.76 0.8 4.9 3.08 4.91 0.007 65 29 10 7/1.35 1 7 1.83 3.08 0.0065 110 52 16 7/1.70 1 8 1.15 1.91 0.005 170 70 25 7/2.14 1.2 10 0.727 1.2 0.005 270 110 35 7/2.52 1.2 11.5 0.524 0.868 0.004 364 150 50 19/1.78 1.4 13 0.387 0.641 0.0045 500 200 70 19/2.14 1.4 15 0.268 0.443 0.0035 688 269 95 19/2.52 1.6 17.5 0.193 0.32 0.0035 953 360 120 37/2.03 1.6 19 0.153 0.253 0.0032 1168 449 150 37/2.25 1.8 21 0.124 0.206 0.0032 1466 551 185 37/2.52 2 32.5 0.099 0.164 0.0032 1808 668
People's Cable Group Co., Ltd. Was founded in 2007, with good transport facilities which adjacent to the 310 national highway-Lian Huo highway. Our company had 2 factories(Zhitian factory and Zhulin factory), occupies total area of more than 300,000 square meters, with building area 230,000 square meters. The real capital assets more than 10 million USD, with 630 staff members, 65 of which are professional and technical experts.
Our mainly products as follow:
1.PVC insulated electric wire whatever copper conductor,aluminum conductor,CCA(copper clad
aluminum),CCS(copper clad steel).
2.PVC insulated power cable and xlpe insulated power cable with or without armor upto 35kv.
3.Rubber cable like welding cable, mining cable, control cable and so on.
4.Aerial bundled cable(ABC cable) up to 10kv, like Duplex ABC cable, Triplex ABC cable, Quadruplex ABC cable and so on.
5.Bare conductor like AAC, AAAC, ACSR, AACSR, ACAR, ACSR/AW, aluminum clad steel wire, galvanized steel wire and so on.
Q1: When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in
your email so that we will regard your inquiry priority.
Q2: How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
Q3: How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days.
The samples will be sent to you via express and arrive in 3~5 days.
Q4: What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
