• Model NO.：Aerial Cable
• Transport Package：Drums
• Specification：100mm2
• Trademark：Yifang
• Origin：China
• HS Code：8544492100
• Production Capacity：1000km Per Week

CONDUCTORBARE
(ANT)PVC
COVEREDBARE
(WASP)PVC CoveredNominal area of Aluminum mm25050100100Approx.Overall diameter of bare conductor mm9.39.313.1713.17Overall diameter of covered conductors-11.7-16Stranding No/mm Al.7/3.17/3.17/4.397/4.39Calculated maxi d.c.resistance at 20 degree(ohm/km)0.54190.54190.27020.2702Calculated minimum breaking load(KN)8.288.281616Approx.mass of conductor
kg/km145200290360
PVC covered conductos shall be manufactuerd in accordance with BS6485
The material, consturction and physical properties of the conductor shall, after covering,conform to BS215 part 1 and clause 4.3.1 of this specification
The PVC covering shall conform to the type TI1 compound as per BS6485
 The colour of the covering shall be black.
The thickness of  PVC covering at any point shall be not less than 0.8mm


Our company

Yifang Electric group mainly specialized in wire&cables,including designment,production and sale.

Products are mainly covering low,medium,high voltage(1KV to 220KV) XLPE Insulated power cable,PVC insulated power cable,ABC cable,building cable control cable,rubber cable welding cable Etc.

Our XLPE cable can be manufactured according to the company's specification which is equivalent to IEC 60502,IEC60332,IEC60754. Some indexes are superior to above international standard.


Our certificate


FAQ

1.Q:Are you a factory or trading company?
 A: Manufacturing base in Henan ,China, with more than 500 workers.

2.Q:How can I visit there?
 A: Sure,If you need,we will arrange the driver to pick you up.

3.Q:How can I get some samples?
 A: Contact me on below,Determin sample and address for shipping.


4.Q:Have you ever supplied cables to our country?
 A: Yifang Cables have been sold to over 100 countries and regions in the world. can you contact me for details.

5.Q:What is your MOQ?
A: MOQ Normally 500 meters for big diameter cables.Please contact me for detail info if you have specific cable requirement.

6. Q:When can I get the price?
A: Usually quote within 6 hours after we get your inquiry.

7.Q:How long is your delivery time?
 A: According to your order's quantity.Usually our lead time is 3 - 20 working days.
