• Model NO.：AAC Bare Conductor
• Material Shape：Round Wire
• Range of Application：Overhead
• Certification：ISO9001
• Brand：Rmjt
• Name：ASTM B231 All Aluminium Strand AAC Conductor
• Standard：ASTM B231 BS215
• Voltage：High Voltage
• Material：All Aluminium Strand
• Delivery Time：15 Days
• Yield：30tons,Day
• Payment：20%T,T Advanced
• Aluminum：Hard Drawn Aluminum 1350-H19
• Purpose：Electrical Transmission Line
• Transport Package：Wooden Drum
• Specification：mcm AWG mm2
• Trademark：RMJT
• Origin：China
• HS Code：7614900000
• Production Capacity：30 Ton,Day

Code NameAreaStranding and wire diameterApprox. Overall diameterWeightNominal breaking loadNom. DC resistance at 20 deg.NominalActualmm2mm2mmmmkg/kmkNohm/kmMIDGE2223.337/2.066.2643.991.227APHIS2526.43/3.357.2734.111.081GNAT2526.87/2.216.6734.591.066WEEVIL3031.63/3.667.9864.860.9082MOSQUITO3537.07/2.597.81016.030.7762        LADYBIRD4042.87/2.798.41176.870.6689ANT5052.837/3.109.31458.280.5419FLY6063.557/3.4010.21749.900.4505BLUEBOTTLE7073.77/3.6611.020211.340.3881EARWING7578.57/3.7811.421511.940.3644        GRASSHOPPER8084.17/3.9111.723012.780.3406CLEGG9095.67/4.1712.526214.530.2995WASP100106.07/4.3913.229016.000.2702BEETLE100106.619/2.6713.429317.420.2704BEE125132.07/4.9014.736119.940.2169        CRICKET150157.97/5.3616.143223.850.1813HORNET150157.619/3.2516.343427.700.1825CATERPILLAR175186.019/3.5317.751228.630.1547CHAFER200213.219/3.7818.958732.400.1349SPIDER225236.919/3.9920.065236.010.1211        COCKROACH250265.719/4.2221.173140.400.1083BUTTERFLY300322.719/4.6523.388848.700.08916MOTH350373.219/5.0025.0102756.370.07711DRONE350373.337/3.5825.1102957.450.07741LOCUST400428.519/5.3626.8117964.730.06710        CENTIPEDE400415.237/3.7826.5114563.100.06944MAYBUG450486.937/4.0928.6134274.010.05931SCORPION500529.537/4.2729.9146079.980.05441CICADA600628.637/4.6532.6173394.950.04588TARANTULA750794.837/5.2336.62191120.100.03627
Construction:

1) Conductor: 1350 Aluminum

2) Sectional area: 10-1000mm2

3) No. of strands (al/st): 7, 19, 37, 61, 91

4) Min. bending radius: 40 times cable radius

Production Line
As one of top rank cables manufacturers in China, our Zhitian factory is mainly specialized in PVC Insulated Building Wire, PVC and XLPE Insulated Power Cable with Voltage up to 35kV, Rubber Cable and Welding Cables. And the Zhulin factory is mainly specialized in Aerial Bundled Cable(ABC Cable), Bare Overhead Power Transmission Line such as All Aluminum Conductor(AAC Conductor), All Aluminum Alloy Conductor(AAAC Conductor), Aluminum Conductor Steel Reinforced(ACSR Conductor), Aluminum Conductor Aluminum Clad Steel Reinforced (ACSR/AW), All Aluminum Alloy Steel Reinforced(AACSR), and Aluminum Conductor Aluminum Alloy Reinforced(ACAR).

Packaging and Shipping

FAQ

1. What is our company's main advantage?

We have produced cables for many years and have rich experience in exporting, and our quality can meet different standards including ASTM, BS, EN, IEC, DIN etc.



2.  What is our payment term?

Generally our payment term is T/T or L/C at sight in trial business.



3. What is the package of the cable ?

The package is strong wooden drum, steel wooden drum or coil, and we can also provide special packing according to customer's requirment.



4. What is the delivery time?

Normally we could send the shipment within 20 days after confirmation. It relates to the cable type, quantity, if you need the specific delivery time or you are urgent, kindly advise us your special needs when you contact us for better checking.



5.Can we provide customers free sample for checking?

Yes, free sample is available for checking, normally courier charge is on customers.
