LMR195 Coaxial Cable Assembly with SMA-N Connectors for Antennas
Otto Cable Technology Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, RF Cable
- Conductor Material：BC,CCS
- Cover Material：PVC,PE,LSZH
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：LMR195
- Wire Core Material：BC,CCS
- Certification：CE, ISO, RoHS
- Model：LMR195
- Brand：Otto Cable
- Transport Package：Pallet; Carton; Spool
- Specification：4.95mm
- Trademark：OTTO CABLE
- Origin：China
- HS Code：8544211000
- Production Capacity：1000PCS,Day
Description
Basic Info.
Model NO. LMR195 Wire Core Material BC/CCS Certification CE, ISO, RoHS Model LMR195 Brand Otto Cable Transport Package Pallet; Carton; Spool Specification 4.95mm Trademark OTTO CABLE Origin China HS Code 8544211000 Production Capacity 1000PCS/DayProduct Description
LMR195 Coaxial Cable Assembly with SMA-N Connectors for Antennas
Application:
• Mobile Antennas
• Wireless Communication Syestems
• WLL, GPS, WLAN,WiMax
• Cellphone Signal Repeaters
• Signal transmission
Features:
• 50 Ohm
• Low Loss RF Cable
• 0 - 6GHz
• Excellent performance at high frequency
• Drop-in replacement for RG58.
• REACH/RoHS compliant, CE certified.
• OEM/ODM
Assemblies:
• N, TNC, BNC, SMA......
• Customized Cable length / color/ roll size/ packing
• Various colors of Heat shrinkable tube
Construction
| Item | Material | Diameter(mm) |
| Inner Conductor Dielectric First Shield Second Shield Jacket | Bare Copper / Copper Clad Steel Foam PE Bonded Aluminum Foil Tinned Copper Wire Braid PVC/PE/LSZH | 0.94 2.79 2.95 3.53 4.95 |
Electrical Characteristics
| Impedance (Ω) Capacitance (pF/m) Velocity of Propagation (%) Return Loss Screening Effectiveness(dB) VSWR Installation Temp(ºC) Operating Temp(ºC) | 50±3 83.3 80 ≥20 ≥90 ≤1.2 -25 to +70 -25 to +70 |
Attenuation (@20ºC)
| Frequency(MHz) | Max Attenuation(dB/100m) |
| 150 220 450 900 1500 1800 2000 2500 | 14.6 17.7 25.5 36.5 47.7 52.5 55.4 62.4 |
