Bare IEC A1/S3a Aluminum Conductor Steel Reinforced ACSR Conductor
People's Cable Group Co., Ltd.- Type：Bare
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum and Steel Wire
- Sheath Material：Bare
- Insulation Material：Bare
Base Info
- Model NO.：ACSR
- Material Shape：Round Wire
- Range of Application：Power Transmission
- Certification：ISO9001, CE, CCC, OHSAS, BV, SGS
- Brand：Rmjt
- Area：10-1000mm2
- Color：Silver
- Voltage：High Voltage
- Current：DC Cable
- Standard：ASTM BS DIN Jb IEC GB GOST
- Factory Area：300, 000mm2
- Transport Package：Wooden Drum or Steel Wooden Drum
- Specification：ASTM BS CSA DIN IEC
- Trademark：RMJT
- Origin：Henan, China
- HS Code：7614100000
- Production Capacity：50000km,Month
Description
Code numberSteel
ratio Areas No. of wires Wire diam. Diameter Linear
mass Rated
strength D.C
resistance
at 20°C Alum. Steel Total Al St. Alum. Steel Core Cond. % mm² mm² mm² mm mm mm mm Kg/km kN Ohn/km 16 17 16 2.67 18.7 6 1 1.84 1.84 1.84 5.53 64.6 6.83 1.7934 25 17 25 4.17 29.2 6 1 2.30 2.30 2.30 6.91 100.9 10.25 1.1478 40 17 40 6.67 46.7 6 1 2.91 2.91 2.91 8.74 161.5 16.20 0.7174 63 17 63 10.5 73.5 6 1 3.66 3.66 3.66 11 254.4 24.15 0.4555 100 17 100 16.7 117 6 1 4.61 4.61 4.61 13.8 403.8 38.33 0.2869 125 6 125 6.94 132 18 1 2.97 2.97 2.97 14.9 397.9 31.04 0.2304 125 16 125 20.4 145 26 7 2.47 1.92 5.77 15.7 503.9 51.39 0.2310 160 6 160 8.89 169 18 1 3.36 3.36 3.36 16.8 509.3 38.67 0.1800 160 16 160 26.1 186 26 7 2.80 2.18 6.53 17.7 644.9 64.99 0.1805 200 6 200 11.1 211 18 1 3.76 3.76 3.76 18.8 636.7 46.89 0.1440 200 16 200 32.6 233 26 7 3.13 2.43 7.30 19.8 806.2 78.93 0.1444 250 10 250 24.6 275 22 7 3.80 2.11 6.34 21.6 880.6 75.60 0.1154 250 16 250 40.7 291 26 7 3.50 2.72 8.16 22.2 1007.7 98.66 0.1155 315 7 315 21.8 337 45 7 2.99 1.99 5.97 23.9 1039.6 85.13 0.0917 315 16 315 51.3 366 26 7 3.93 3.05 9.16 24.9 1269.7 121.20 0.0917 400 7 400 27.7 428 45 7 3.36 2.24 6.73 26.9 1320.1 106.10 0.0722 400 13 400 51.9 452 54 7 3.07 3.07 9.21 27.6 1510.3 137.56 0.0723 450 7 450 31.1 481 45 7 3.57 2.38 7.14 28.5 1485.2 115.87 0.0642 450 13 450 58.3 508 54 7 3.26 3.26 9.77 29.3 1699.1 154.75 0.0643 500 7 500 34.6 535 45 7 3.76 2.51 7.52 30.1 1650.2 128.74 0.0578 500 13 500 64.8 565 54 7 3.43 3.43 10.30 30.9 1887.9 171.94 0.0578 560 7 560 38.7 599 45 7 3.98 2.65 7.96 31.8 1848.2 144.19 0.0516 560 13 560 70.9 631 54 19 3.63 2.18 10.90 32.7 2103.4 192.45 0.0516 630 7 630 43.6 674 45 7 4.22 2.81 8.44 33.8 2079.2 162.21 0.0459 630 13 630 79.8 710 54 19 3.85 2.31 11.60 34.7 2366.3 213.32 0.0459 710 7 710 49.1 759 45 7 4.48 2.99 8.96 35.9 2343.2 182.81 0.0407 710 13 710 89.9 800 54 19 4.09 2.45 12.30 36.8 2666.8 240.41 0.0407 800 4 800 34.6 835 72 7 3.76 2.51 7.52 37.6 2480.2 176.74 0.0361 800 8 800 66.7 867 84 7 3.48 3.48 10.40 38.3 2732.7 224.00 0.0362 800 13 800 101 901 54 19 4.44 2.61 13.00 39.1 3004.9 270.88 0.0362 900 4 900 38.9 939 72 7 3.99 2.66 7.98 39.9 2790.2 198.83 0.0321 900 8 900 75 975 84 7 3.69 3.69 11.10 40.6 3074.2 244.50 0.0322 1000 4 1000 43.2 1043 72 7 4.21 2.80 8.41 42.1 3100.3 220.93 0.0289 1120 4 1120 47.3 1167 72 19 4.45 1.78 8.90 44.5 3464.9 247.77 0.0258 1120 8 1120 91.2 1211 84 19 4.12 2.47 12.40 45.3 3811.5 307.79 0.0258 1250 8 1250 52.8 1303 72 19 4.70 1.88 9.40 47 3867.1 276.53 0.0231 1250 4 1250 102 1352 84 19 4.35 2.61 13.10 47.9 4253.9 343.52 0.0232
5.About US
People's Cable Group Co., Ltd. was founded in 2007, located in Zhengzhou Gongyi economic development zone. Our company has 2 factories (Zhitian factory and Zhulin factory), occupies total area of more than 300,000 square meters, with building area 230,000 square meters. The real capital assets more than USD 10 million , with total 500 staff members, 65 of which are professional and technical experts.
6.Certificate
As first rank of the cable supplier in China, we have obtained CCC, ISO9001, ISO14001, OHSAS certificates, passed the SGS and BV test, and our brand "RMJT" be given China famous brand.
7.Customer Visit
We have a professional sales team with each of them has engaged in this job for 3-10 years, so that we can provide the comprehensive and professional technology for you. With the perfect quality and after sales service, till now we have exported to more than 80 countries, welcome to visit us and establish win-win relationship!
8. FAQ
1) What is our company's main advantage?
We have produced cables for many years and have rich experience in exporting, and our quality can meet different standards including ASTM, BS, EN, IEC, DIN etc.
2) What is our payment term?
Generally our payment term is T/T or L/C at sight in trial business.
3) What is the package of the cable ?
The package is strong wooden drum, steel wooden drum or coil, and we can also provide special packing according to customer's requirment.
4) What is the delivery time?
Normally we could send the shipment within 20 days after confirmation. It relates to the cable type, quantity, if you need the specific delivery time or you are urgent, kindly advise us your special needs when you contact us for better checking.
5) Can we provide customers free sample for checking?
Yes, free sample is available for checking, normally courier charge is on customers.
6) Which markets have we exported to?
We have exported to many Countries, mainly, South-east Asia, Middle East, Africa, South America, North America and Europe etc.
9.Contact Us
People's Cable Group Co.,Ltd
Factory ADD:No.13th,YongDing Road, Goingyi,Zhengzhou city, Henan province, China.
