8/12/24 Core GYTC8S Fig8 Aerial Armour Optical Fiber Cable
DONGGUAN TW-SCIE CO., LTD.- Application：Communication, Art, Sensor, Medicine, Probe, Fiber Optic Cable
- Type：Single More or Multimode
- Connection Structure：Fiber Optic Cable
- Material Shape：Round Wire
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：1000N<10000N
Base Info
- Model NO.：GYTC8S fiber optic cable
- Core：Double Core
- Certification：RoHS, ISO9001, Reach
- Brand：OEM or Tw-Scie
- Sheath Material：LSZH, HDPE, MDPE
- Jacket Material：Black PE Fiber Optic Cable
- Messenger Material：Steel Wires
- Installation Style：Aerial Fiber Optic Cable
- Brand Name of Fiber：Corning, Yofc, Draka, ...as Your Requirement
- Loose Tube Material：PBT with Jerry Optical Cable
- Waterblocking Material：Water Blocking Tape or Filling Compound
- Outer Sheath Material：MDPE , HDPE , LSZH Optical Cable
- Armour Material：Corrugated Steel Tape
- Stranding Member：Steel Wire or FRP
- Fiber Count：2-288 Core Fiber Optical Cable
- Transport Package：Wooden Drum
- Specification：GYTC8S
- Trademark：TW-SCIE or OEM
- Origin：Dongguan China
- HS Code：8544700000
- Production Capacity：150km,Day
Description
Cable Sheath Marking
Each cable have the following information clearly marked on the outer jacket of cables:
a. Name of manufacturer.
b. Year of manufacturer
c. Type of cable and fiber
d. Length mark (printing on each meter normally)
e. Or as customer's requirements.
Cable Performance
| Item | Testing | Test Method | Test Result |
| 1 | Tensile strength IEC 60794-1-E1 | Long term: 2500N Short term: 4950N Cable length: ≥50m | Loss change≤0.1dB@1550nm No fiber break and no sheath damage |
| 2 | Impact IEC 60794-1-E4 | Height: 1m Weight: 1kg Impact spot: ≥5 Impact cycle: at lease 3 cycle per spot | Loss change≤0.1dB@1550nm No fiber break and no sheath damage |
| 3 | Repeated Bending IEC 60794-1-E6 | Bending diameter: 25X the cable outer diameter Applied load: 25kg Bending cycle: 30times Bending speed: 1 cycle per 2s | Loss change≤0.1dB@1550nm No fiber break and no sheath damage |
| 4 | Torsion IEC 60794-1-E7 | Torsion length: 1m Applied load: 25kg Torsion angle: ±90 or +180 Twist cycle: ≥10 times | Loss change≤0.1dB@1550nm No fiber break and no sheath damage |
| 5 | Water Penetration IEC 60794-1-F5B | Water height: 1m Cable length: 3m Keeping time: 24hours | No water leaked from the opposite end of cable |
| 6 | Temperature IEC 60794-1-F1 | Temperature step:+20°C->-40°C°C >+70°C->+20°C Keeping time: 24hours per each step Cycle:2times | Loss change≤0.1dB@1550nm No fiber break and no sheath damage |
| 7 | Compound flow IEC 60794-1-E14 | Sample length: 30cm Temperature: 70ºC±2ºC Keeping time: 24hours | No compound flow |
Advantages
1.OEM fiber optic cable manufacturer
2. Fiber brand : YOFC, CORNING,FUJIKURA
3.Quality certification :ISO9001.ROSH.REACH
4.Cooperate with Vietnam telecom, Thai telecom, Singapore telecom, Dubai telecom and other big projects
5.Tw-scie known as the fiber optic cable manufacturer for the excellent products quality,competitive prices , fast delivery and good service
GYTC8S 6 Core Optical Fiber Cable Main Export Markets
· Central/South America
· Mid East/Africa
· Eastern Europe
· North America
· Asia
· Western Europe
· Australasia
Why Choose US?
1.Introduction of foreign advanced production equipment and technology, have 20 years production experience, 80% employees have more than 10 years experience, excellent enterprise culture and management team.
2.FAST SHIPPING from factory
3.Item shipped in 3-15 working days after payment is received depends on the quantity of the order.
4.We accept T/T, L/C, Western Union, Money Gram and Paypal, just choose what you like.
5.We accept OEM. The cable size and material are customized. Your own logo and own design are welcome. We will produce according to
ur requirement and description;
6.With more than 20 years experience in fiber optic cable,we already cooperated and established long-term business relationship with both
domestic and overseas famous enterprise.
Contact us:
We highly appreciate your any enquiry by email, fax or instant message. We will reply your email or fax within 12 hours. Please fell free to call us at any time if there is any questions.
Transportation:
· All available shipping ways could be applied, by courier, air or sea.
· Appointed shipping company or our own forwarders all could be used in shipment.
· Full-way tracking the cargos for you before the goods arrive.
Dear Friend,
Thanks for your visiting. Our company--- Dongguan TW-SCIE Co.,LTD supply CATV& FTTx products, including Outdoor & indoor 6 Core
Optical Fiber Cable, Installation tools,Test and inspection equipments, accessories etc...
You are warmly welcome to Browse our products showing in Alibaba and also welcome to visit our website.
Any interesting item or have any confusion,please do not hesitate to contact us.
