Sc APC Single Mode 3.0 mm Simple Patch Cable LC Sm OS2 Fiber Optic Jumper
Takfly Communications Co., Ltd.- Application：Telecommunication,CCTV,Network
- Type：Single-mode Fiber
- Connection Structure：SC
- Material Shape：Round Wire
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：>10000N
Base Info
- Model NO.：Patch Cord
- Core：Single Core
- Certification：RoHS, UL, CE, ISO9001, VDE, CCC
- Brand：OEM
- Sheath Material：PVC
- Jacket：PVC,LSZH,Ofnr,Ofnp,TPU
- Fiber Type：Sm,mm
- Cable Diameter：0.9mm, 2.0mm, 3.0mm
- Connector：Sc,FC,LC,St
- Polishing：APC, Upc, PC
- Insertion Loss：≤0.3dB
- Transport Package：Bag+Carton
- Specification：CE RoHS ISO
- Trademark：Takfly
- Origin：China
- HS Code：8517709000
- Production Capacity：10000PCS,Week
Description
Basic Info.
Model NO. Patch Cord Core Single Core Certification RoHS, UL, CE, ISO9001, VDE, CCC Brand OEM Sheath Material PVC Jacket PVC,LSZH,Ofnr,Ofnp,TPU Fiber Type Sm/mm Cable Diameter 0.9mm, 2.0mm, 3.0mm Connector Sc,FC,LC,St Polishing APC, Upc, PC Insertion Loss ≤0.3dB Transport Package Bag+Carton Specification CE RoHS ISO Trademark Takfly Origin China HS Code 8517709000 Production Capacity 10000PCS/WeekProduct Description
SC/APC Single Mode 3.0 mm Simple Patch Cable LC SM OS2 Fiber Optic Jumper DescriptionOptic fiber patch cord
Also called jumper cable & optic fiber cable connector,patch cords from equipment to fiber optic cabling links,refers to the connector plugs on both ends of the fiber optic cable,used to realize the optical path active connection,one end with a plug is called a pigtail,generally used for the connection between the optical transceiver and the terminal box.
Features
>> Low insertion loss and High reflection loss
>> Good exchange ability
>> Good durability
>> High temperature stability
>> Standard:Telcordia GR-326-CORE
Applications
>> CATV
>> Telecommunication networks
>> Active device termination
>> Local area networks(LANS)
>> Data processing networks
>> Test equipment
>> Wide area networks(WANS)
Specifications
| End Face Type | PC, UPC, APC |
| Fiber Type | SM (G652D, G655, G657A1, G657A2, G657B3; MM (OM1~OM5) |
| Cable Diameter | 0.9mm, 2.0mm, 3.0mm or customized |
| Cable Core | Simplex, Duplex |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | UPC SM≥50dB, APC SM≥ 60 dB, PC MM≥ 35 dB |
| Repeatability | ≤ 0.1 |
| Durability | ≤ 0.2dB |
| Interchangeability | ≤ 0.2dB |
| Tensile Strength | >70N (with good aramid yarn) |
| Operating Temperature | -20ºC~70ºC |
| Storage Temperature | -40ºC~80ºC |
| Outer Sheath Material | PVC, LSZH, TPU, etc.. |
| Bending Radius (Static/Dynamic) | 10D/20D |
| Length | Customized |
