Electric Wire Fiberglass Braided Silicone Wire H05sj-K with VDE Certificate Cable
SHENZHEN MYSUN INSULATION MATERIALS CO., LTD.- Type:Insulated
- Conductor Type:Stranded
- Application:Internal Wire
- Conductor Material:Copper
- Sheath Material:Fiberglass
- Insulation Material:Silicone Rubber
Base Info
- Model NO.:H05SJ-K
- Material Shape:Round Wire
- Range of Application:FT2
- Certification:ISO9001, CE, UL, RoHS
- Brand:Mysun
- Rated Voltage:450V,750V
- Rated Temp:180c
- Color:White, Black, Red, Brown, Yellow, Blue etc
- Transport Package:Cartons
- Specification:0.5-2.5sqmm
- Trademark:MYSUN
- Origin:China
- HS Code:8544492900
- Production Capacity:2000000m,Day
Description
ConductorInsulation Diameter
(mm) Max.cond
resistance
(Ω/km) Unit Length
(m)(Ft) Section
(mm²) Construction
(No./mm) Diameter
(mm) Nominal Thickness
(mm) Fiberglass Thickness
(mm) 0.50 20/0.18 0.92 0.70 0.15 2.62 40.1 305/1000 0.75 30/0.18 1.13 2.83 26.7 1.00 40/0.18 1.31 3.01 20 1.50 30/0.254 1.60 0.80 3.50 13.7 200/656 2.50 50/0.254 2.08 0.85 4.08 7.16
(mm)
resistance
(Ω/km)
(m)(Ft)
(mm²)
(No./mm)
(mm)
(mm)
(mm)
Service
Shipment:
1. by express
2. by sea
Payment terms:
LC, TT, Western Union, Money Gram and PayPal
Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days
