• Model NO.：Type G-GC and Type G
• Wire Core Material：Tinned Wire
• Certification：ISO, CCC, RoHS, UL
• Model：Diesel Locomotive Cable, Dlo
• Brand：Renda
• Products Name：Diesel Locomotive Cable, Dlo Cable
• UL Listed Type：Type Rhh-Rhw-2, Type Dlo Cable
• Standard：UL2806, UL44
• Rated Voltage：600V, 2000V
• Insulation：Epr, EPDM, Ep
• Sheath：CPE, Sun Resistance, Oil Resistance
• Working Temperture：Max 90 Degree or 105degre
• RoHS：Yes
• Msha Approved：Yes
• Character：Resists Oils, Acids, Alkalies, Heat
• Transport Package：Roll, Reel, Coil as Your Requirements
• Specification：12AWG, 10AWG TO 1111.1Kcmil
• Trademark：RENDA
• Origin：China
• HS Code：8544492100
• Production Capacity：10000000FT,Month

Basic Info.

Model NO. Type G-GC and Type G Wire Core Material Tinned Wire Certification ISO, CCC, RoHS, UL Model Diesel Locomotive Cable, Dlo Brand Renda Products Name Diesel Locomotive Cable, Dlo Cable UL Listed Type Type Rhh-Rhw-2, Type Dlo Cable Standard UL2806, UL44 Rated Voltage 600V, 2000V Insulation Epr, EPDM, Ep Sheath CPE, Sun Resistance, Oil Resistance Working Temperture Max 90 Degree or 105degre RoHS Yes Msha Approved Yes Character Resists Oils, Acids, Alkalies, Heat Transport Package Roll, Reel, Coil as Your Requirements Specification 12AWG, 10AWG TO 1111.1Kcmil Trademark RENDA Origin China HS Code 8544492100 Production Capacity 10000000FT/Month

Product Description

Portable Cords and Cables Rubber, TYPE G OR GGC,
Copper EPDM CPE 2000V PORTABLE POWER CABLE
Type W Portable Power Cable
Industrial Grade Single and Multiconductor Portable Round Power Cable
2000 Volt. 90°C (-40°C). Oil and Sunlight Resistant.
Single Conductors Listed as Type RHH/RHW-2.
UL and c(UL) Listed.MSHA Approved. RoHS Compliant
Applications

• Type W Portable Power Cable is suitable for use in industrial and light-to-medium mining applications, heavy-duty service and temporary power supply cables. Motor, battery and generator lead. It is also used for mobile and portable electrical equipment.

STANDARDS & REFERENCES
• UL Listed - Type W per UL 1650
• Conductors are manufactured in accordance with ASTM and B-172
• Made in accordance with ICEA S-75-381
• NEMA WC-58 - Portable and Power Feeder Cables for Use in Mines and Similar Locations
• MSHA accepted
• UL Listed as Type RHH or RHW-2
• c(UL) Certified as applicable
• RoHS Compliant

CONSTRUCTION
Type W portable power cables are manufactured with rope-lay-stranded, bunched members, annealed copper conductors. A polyester or paper tape separates the copper conductors from the EP rubber insulation. The insulated conductors have assembled around with fillers as needed. The cable is covered with a black CPE rubber jacket. Jackets are reinforced by a braid or serve of synthetic material. Sizes 8 AWG through 500 MCM fully annealed stranded bare copper per ASTM B-172.
Types G, G-GC, W
Types G, G-GC, SHD, SHD-GC, W.
