Shd-Gc 25kv Rubber Power Portable Mine Cable
Hebei Huatong Wires & Cables Group Co., Ltd.- Application：Mining
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：Rubber
- Sheath Material：Rubber
- Material Shape：Round Wire
Base Info
- Model NO.：Mine Cable
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE, TUV
- Model：UC UCP
- Brand：Rneda
- Certificate：ISO CCC CE TUV
- Usage：Mining
- Conductor：Flexible Copper
- Core：3
- Transport Package：Wooden Drum
- Specification：IEC DIN ASTM VDE BS
- Trademark：RNEDA
- Origin：China
- HS Code：8544492100
- Production Capacity：100km,Month
Description
Physical Properties
Power cores
Conductor sizes (mm2)
16
25
35
50
70
95
120
150
Maximum wire diameter ( mm)
0.41
0.41
0.41
0.51
0.51
0.51
0.51
0.51
Approx. conductor diameter ( mm)
5.3
6.8
8.5
10.3
11.9
13.5
15.5
17.3
Maximum screen wire diameter (mm)
0.31
0.31
0.31
0.31
0.31
0.31
0.31
0.31
Braided screen filling factor (%)
80
80
80
80
80
80
80
80
Approx. summarized screen cross-section for power cores
(weighing method) (mm2)
22
25
27
32
37
43
47
52
Pilot cores
Conductor sizes ( mm2)
10
10
16
16
16
16
16
16
Maximum wire diameter ( mm)
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
Approx. conductor diameter ( mm)
4.2
4.2
5.3
5.3
5.3
5.3
5.3
5.3
Lay Ratio (maximum) (x PCD)
8
8
8
8
8
8
8
8
Cable diameter
Approx. (mm)
31
38
43
47
52
58
63
70
Cable mass (approx.) (kg/m)
1.8
3.1
3.6
4.5
5.6
7.0
8.4
10.2
Minimum bending radius (mm)
200
240
260
290
320
350
390
430
Maximum recommended tension (kN)
0.7
1.1
1.6
2.3
3.2
4.3
5.4
6.8
