Manufacture Flexible RF Coaxial Cable 50 Ohm Rg 400 Double Braiding Shield Cable for High Temperature

Jiangsu Elesun Cable Co., Ltd.
  • Application：Local Communication Cable, Coaxial Cable, Long Distance Symmetric Cable, RF Cable, Submarine Cable, Antenna Cable
  • Conductor Material：Sc, Sccs
  • Cover Material：FEP
  • Type：Rg400
  • Material Shape：Round Wire
  • Conductor Type：Stranded

Base Info

  • Model NO.：RG400
  • Wire Core Material：Sccs
  • Certification：CE, ISO, RoHS, CCC, UL
  • Model：Rg400
  • Brand：Elesun
  • Material of Inner Conductor：Silver Copper
  • Structure of Inner Conductor：19,0.20mm
  • Material of Insulation：PTFE
  • Diameter of Insulation：3.00mm
  • Material of Braiding(Shielding)：Silver Copper
  • Structure of Braiding(Shielding)：144+168*0.15mm
  • Material of Jacket：FEP
  • Diameter of Jacket：4.95mm
  • Working Temp：-55ºC,200ºC
  • Impedance：50Ω±2
  • Voltage：3000V
  • Transport Package：500m,Reel,CTN
  • Specification：38*38*30cm
  • Trademark：ELESUN
  • Origin：China
  • HS Code：8544200000
  • Production Capacity：10000m,Day

Description

RG400/U coaxial cable specificationsMaterial of Inner ConductorSilver CopperStructure of Inner Conductor19/0.20mmMaterial of Insulation PTFEDiameter of Insulation3.00mmMaterial of Braiding(Shielding)Silver CopperStructure of Braiding(Shielding)144+168*0.15mmMaterial of Jacket FEPDiameter of Jacket4.95mmWorking temp-55ºC/200ºCImpedance50Ω±2Voltage3000V
