• Model NO.：elevator cable
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, CCC, RoHS
• Produceing Experience：15 Years
• Size(mm2)：0.75~25
• More Size：Customized According to Your Request
• OEM：Yes
• Export Experience：Southeast Asia,South America,Russia
• Transport Package：Coil, Drum or as Per The Customer′s Request
• Specification：SGS
• Origin：Henan
• HS Code：8544492100
• Production Capacity：500km Per Month

Basic Info.

Model NO. elevator cable Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, CCC, RoHS Produceing Experience 15 Years Size(mm2) 0.75~25 More Size Customized According to Your Request OEM Yes Export Experience Southeast Asia,South America,Russia Transport Package Coil, Drum or as Per The Customer′s Request Specification SGS Origin Henan HS Code 8544492100 Production Capacity 500km Per Month

Product Description

Flat Flexible Traveling Elevator cable

1.15years producing experience
2. OEM is available.
3. Speical types and sepcifications can be Customized.

4.Description of cable:

Conductor :  Stranded bare Copper wire,
                     Conductor class5 Acc. to VDE0295
Insulation:    Speical Compounded PVC
Bearing:       Steel Rope
Sheathing:   Speical Compounded PVC ,
                    Cold resistance , flame resistance
Color of sheathing: grey , black

Specification:
Core Nos.:  2core, 3core, 4core,.........16C,17C,.....20C.21C.22C...66Core
Nominal Section Area:0.75mm2,...~ 25mm2
More size and specification can be customized

Technical Data:
Rated voltage:  300/500V
Test voltage:     2500V
Minimum bending radius: 0.3m<L<0.3m
Used under normal conditions,the temperature of conductor is lower than 70°C
Temperature range:-15°C to +70°C


Packing:
1.100meter per roll then put into plastic bags or carton
2. at least 500meter per drum
