• Model NO.：K-HP-1113
• Material Shape：Round Wire
• Range of Application：Machinery,Thermocouple,Electricity
• Certification：ISO9001, ANSI
• Brand：Ohmalloy
• Transport Package：100m,Spool, 305m,Spool, 1000FT,Spool, 1000m,Spool
• Specification：AWG 20 AWG 18 AWG 8
• Trademark：OHMALLOY
• Origin：China
• Production Capacity：500000meters Per Month

Thermocouple Variety and Index
Variety
Type
Measurement Range(°C)
NiCr-NiSi
K
-200-1300
NiCr-CuNi
E
-200-900
Fe-CuNi
J
-40-750
Cu-CuNi
T
-200-350
NiCrSi-NiSi
N
-200-1300
NiCr-AuFe0.07
NiCr-AuFe0.07
-270-0



3 . Dimensions and Tolerance of Fiberglass Insulated Thermocouple Wire

Dimensions / Tolerance mm ) : 4.0+-0.25

Color code & initial calibration tolerances for thermocouple wire:

Thermocouple TypeANSI Color CodeInitial Calibration TolerancesWire AlloysCalibration+/-
ConductorJacketTemperature RangeStandard
LimitsSpecial
LimitsIron(+) vs.
Constantan(-)JWhite/RedBrown0°C to +285°C
285°C to +750°C±2.2°C
± .75%±1.1°C
± .4%CHROMEL(+) vs.
ALUMEL(-)KYellow/RedBrown-200°C to -110°C
-110°C to 0°C
0°C to +285°C
285°C to +1250°C± 2%
±2.2°C
±2.2°C
± .75%±1.1°C
± .4%Copper(+) vs.
Constantan(-)TBlue/RedBrown-200°C to -65°C
-65°C to +130°C
130°C to +350°C± 1.5%
±1°C
± .75%± .8%
± .5°C
± .4%CHROMEL(+) vs.
Constantan(-)EPurple/RedBrown-200°C to -170°C
-170°C to +250°C
250°C to +340°C
340°C+900°C± 1%
±1.7°C
±1.7°C
± .5%±1°C
±1°C
± .4%
± .4%

Color Code & Initial Calibration Tolerance for Extension Wire:

Extension typeANSI Color CodeInitial Calibration TolerancesWire AlloysCalibration+/-
ConductorJacketTemperature RangeStandard
LimitsSpecial
LimitsIron (+) vs. Constantan(-)JXWhite/RedBlack0°C to +200°C±2.2°C±1.1°CCHROMEL (+) vs. ALUMEL (-)KXYellow/RedYellow0°C to +200°C±2.2°C±1.1°CCopper(+) vs. Constantan(-)TXBlue/RedBlue-60°C to +100°C±1.1°C± .5°CCHROMEL(+) vs. Constantan(-)EXPurple/RedPurple0°C to +200°C±1.7°C±1.1°C

PVC-PVC Physical Properties:

CharacteristicsInsulationJacketAbrasion ResistanceGoodGoodCut Through ResistanceGoodGoodMoisture ResistanceExcellentExcellentSolder Iron ResistancePoorPoorService Temperature

105ºC continuous

150ºC single

105ºC continuous

150ºC single

Flame TestSelf-extinguishingSelf-extinguishing
