Chromel Constantan wire /rod /strip E type thermocouple wire EP EN (type E)

Shanghai Tankii Alloy Material Co., Ltd.
  • Type：Bare
  • Conductor Type：Solid
  • Application：Heating
  • Conductor Material：Chromel Constantan
  • Sheath Material：Bare
  • Insulation Material：non

Base Info

  • Model NO.：E
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, RoHS
  • Brand：Tankii
  • Dia：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mmm
  • Bare wire surface：Bright, oxidized
  • Grade：I,II,III
  • Standard：IEC,GB,ANSI,BS,DIN
  • Shape：Wire, rod, strip, flat wire
  • EP：Chromel thermocouple wire
  • EN：Constantan thermocouple wire
  • Brand name：Tankii alloy thermocouple wire
  • MTC：Yes
  • RoHS：Yes
  • Transport Package：Roll with Plastic Film Wrapped and Carton Package
  • Specification：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mm
  • Trademark：TANKII
  • Origin：China
  • HS Code：7505220000
  • Production Capacity：10000 Mt,Year

Description

Chemical CompositionConductor NamePolarityCodeNominal Chemical Composition /%NiCrCuNiCrPositiveEP9010--Cu-Ni(Constantan)NegativeEN45--55Working Temperature Range of thermocouple wireDiameter/mmLong time Working temperature /ºCShort period Working temperature /ºC 0.3,  0.53504500.8, 1.0, 1.24505501.6,  2.05506502.56507503.2750900
