Jb-750 / Ob-750 PVC Control and Connection Cable 450/750 V

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：JB-750 , OB-750
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemCopper wire bare, finely stranded acc. to DIN VDE 0295 Class 5 / IEC 60228 Class 5ConductorCopper wire bare, finely stranded acc. to DIN VDE 0295 class 5 / IEC 60228 class 5InsulationPVC acc. to DIN VDE 0207-363-3 / DIN EN 50363-3 (compound type TI2)Outer SheathPVC acc. to DIN VDE 0207-363-4-1 / DIN EN 50363-4-1 (compound type TM2)Nominal voltageAC Uo /U 450/750 V fixed and protected installation
AC Uo /U 600/1000 VTest voltage core/core4000 VBreakdown voltage 8000 VTemperature RangeFlexible -15°C to +80°C
Fixed -40°C to +80°CColorOptionalCertificationCEApplicationUsed for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use as a connection and control cable in machine tools, assembly lines, conveyor belts, production lines, plant construction, heating and air-conditioning technology, power plants, smelters and steel mills.
