• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS, ETL
• Model：Cat5
• Brand：Risun
• Color：Gray, White, Black
• Inner Conductor：23AWG Bc,CCA
• Nom. Thick：0.6mm
• Export Length：100m,Roll, 200m,Roll, 305m,Roll
• Pairs：4 Pairs
• Transport Package：Pull out Box, Carton Box, Pallet
• Specification：0.56cu, 1.00HDPE, 6.0PVC, LSZH, PE
• Trademark：Risun
• Origin：Zhejiang, China
• HS Code：8544491100
• Production Capacity：30000boxes,Month

Overview

Product Description



ConstructionConductor24AWG(Solid or Strand) CU/CCA/CCSInsulationHDPE 0.90± 0.06mmCores/Pairs8/4Sheath5.20+/-0.1mm PVC (FR,RoHS,UV)/ LSOH / PEMechanical PropertiesElongationMin. 300%Temperature Range-20 up to +75° CTensile strengthMin. 1.68Kg/mm2Electrical Properties (at 20°C)Conductor ResistanceMax. 9.38 ohm/100mResistance UnbalanceMax. 2%Insulation Resistance150 ohm/KMMutual CapacitanceMax. 5600pF/100mCpacitance UnbalanceMax. 330pF/100mImpendance100+/-15 ohmSpark Test2000VVelocity Propagation67%

Detailed Photos

Application

Certifications



Company Profile

Packaging & Shipping

FAQ

FAQ

Q1. ARE YOU TRADING COMPANY OR MANUFACTURER?

A: We are factory.


Q2. HOW LONG IS YOUR DELIVERY TIME?

A:Generally it is  5-10 days, or it is 20-30 days if the goods are not in stock,its is according to quantity.


Q3. DO YOU HAVE ANY MOQ LIMIT FOR ORDER?

A: Normally, 10kms per one specification and one color


Q4. DO YOU PROVIDE SAMPLES? IS IT FREE OR EXTRA?A: Yes,we welcome sample order to test and check quality.we could offer the sample for free charge but do not pay freight.


Q5. HOW TO PROCEED AN ORDER FOR CABLES?

A: Firstly let us know your requirements or application.
    Secondly We quote according to your requirements or our suggestions.
    Thirdly customer confirms the samples and places deposit for formal order.
    Fourthly We arrange the production.


Q6.IS IT OK TO PRINT MY LOGO ON CABLES ?
A: Yes. Please inform us formally before our production.

Q7. WHAT IS YOUR TERMS OF PAYMENT?
A: Payment<=60km,100% in advance,payment >=60KM,30%TT in advance ,balance before shipment .

            WELCOME TO RISUN!!!
