F/UTP FTP 4 Pairs Cable Category 6A PVC Sheath

Hangzhou Risun Cable Co., Ltd.
  • Application：Local Communication Cable, LAN Cable, Network Cable Ethernet Cable
  • Conductor Material：Copper
  • Cover Material：PVC
  • Material Shape：Round Wire
  • Conductor Type：Solid
  • Certification：CE, ISO, RoHS, CCC, ETL,CPR

Base Info

  • Brand：Risun or OEM
  • Insulation：HDPE
  • Conductor Diameter：0.565mm
  • Shield：Polyester,Aluminum Shield
  • Transport Package：305m,Wooden Drum
  • Origin：Hangzhou, Zhejiang, China
  • HS Code：8544491100
  • Production Capacity：20000 Boxes , Month

Description

Basic Info.

Brand Risun or OEM Insulation HDPE Conductor Diameter 0.565mm Shield Polyester/Aluminum Shield Transport Package 305m/Wooden Drum Origin Hangzhou, Zhejiang, China HS Code 8544491100 Production Capacity 20000 Boxes / Month

Product Description

 Configuration

1. Conductor: 0.565±0.005mm Bare copper
2. Insulation: 1.12±0.05mm HDPE
3. Shield: Pet/Al Foil
4. Drain wire:TC
5. Ripcord
6. Sheath: 7.3±0.3mm PVC

Electrical Specifications

dc Resistance, maximum7.61 ohms/100 m | 2.32 ohms/100 ft
Mutual Capacitance at Frequency4.2 nF/100 m @ 1 kHz
Nominal Velocity of Propagation (NVP)79 %
Operating Frequency, maximum500 MHz

Packing

1) packing lengths: 305m/wooden drum, or other lengths available according to client's request.
2) inner packing: wooden reel, plastic reel, and paper reel available.
3) outer packing: carton box, pull box
4) other packing available according to client's request.
5) any question, please contact us without hesitation. we'll reply as soon as we can.

Company Profile
 Risun is a manufacturer and exporter of high quality lan cable/network cable,coaxial cable, alarm cable and  telephone cable in china. 95% of our goods for the export market. 15 years of experience in this field makes us very familiar with export handling.In the past 15 years, we have already get ETL, CE, ROHS, ISO9001,CPR certification.

We are committed to providing you with high-quality and competitive products.We will be your trusted partner.
 F/UTP FTP 4 Pairs Cable Category 6A PVC Sheath

process of production:

F/UTP FTP 4 Pairs Cable Category 6A PVC Sheath
Certificate

F/UTP FTP 4 Pairs Cable Category 6A PVC SheathWelcome to RISUN,we will be happy to serve you!
