Nyry, Power Cable, 0.6/1 Kv, 1/C, Cu/PVC/PVC/Awa/PVC (IEC 60502-1)
Jiangsu Boan Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Underground
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：NYRY
- Material Shape：Round Wire
- Range of Application：Underground
- Certification：ISO9001, CE, CCC
- Brand：Boan
- Rated Voltage：0.6,1 Kv
- Class of Conductor：2
- Number of Cores：1
- Size：10-630 Mm2
- Type of Armour：Aluminum Wire
- Transport Package：Heated Steel-Wooden Drum,Steel Drum
- Specification：SGS
- Trademark：DingAn or OEM
- Origin：Jiangsu Yixing, China
- HS Code：8544492100
- Production Capacity：38000 Km,Year
Description
Conductor DiameterInsulation Thickness Bedding Thickness Armour Diameter Sheath Thickness Overall Diameter Cable Weight No.xmm² mm mm mm mm mm mm Kg/Km Single Core PVC Insulated AWA Armoured Power Cable 1x10 4 1 1 0.8 1.8 14 300 1x16 5 1 1 0.8 1.8 15 375 1x25 6.3 1.2 1 0.8 1.8 16 500 1x35 7.4 1.2 1 0.8 1.8 18 625 1x50 8.8 1.4 1 1.25 1.8 20 835 1x70 10.6 1.4 1 1.25 1.8 22 1075 1x95 12.4 1.6 1 1.25 1.8 24 1385 1x120 14 1.6 1 1.6 1.8 26 1700 1x150 15.5 1.8 1 1.6 1.8 28 2025 1x185 17.4 2 1 1.6 1.8 31 2450 1x240 20.3 2.2 1 1.6 1.9 34 3100 1x300 22.7 2.4 1 2 2 38 3900 1x400 25.4 2.6 1.2 2 2.1 42 4875 1x500 28.8 2.8 1.2 2 2.2 45 6050 1x630 30.4 2.8 1.2 2 2.4 50 7625
