Light/Heavy Duty Copper Conductor and Sheath Mg0 Insulated Fire Proof Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Underground, Indoor Fixed Installations in Dry Locations
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：NG-A
- Material Shape：Round Wire
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Rate Voltage：0.6,1kv
- OEM：Yes
- Transport Package：Wooden Box Packing or Pallet Shipping Containers
- Specification：copper,pvc
- Trademark：Feiya
- Origin：China
- HS Code：8544492100
- Production Capacity：80000 Meter,Meters Per Month
Description
IEC60702-1
GB13033.2
Q/321023KLA36
BTTVQ
Light duty copper conductor and sheath PVC covering Mg0 insulated fire proof cable
BTTZ
Heavy duty copper conductor and sheath Mg0 insulated fire proof cable
BTTVZ
Heavy duty copper conductor and sheath PVC covering Mg0 insulated fire proof cable
Specification
Type
Rated voltage
V
Number of core
Nominal cross-section
mm2
BTTQ BTTVQ
500
1,2
1~4
3,4,7
1~2.5
BTTZ BTTVZ
750
1
1.5~400
2,3,4
1.5~25
7
1.5~2.5
5,10,12,19
1.5
Main characteristics of the cable
1,It has good fire proof, anti-explosion and water proof performance;
2,It has LS0H and non-toxicity characteristic;
3,It has strong high temperature and corrosion resistant capability;
4,It is radiation resistant, and electromagnetic resistant;
5,It has a big current-carrying capacity and strong over-loading capability;
6,It has good earthing performance.
Technical parameter:
Type
Number of core and nominal cross-section
Outer diameter
Rated current-carrying capacity
Approximate weight
Bare cable
Cable with anti-corrosion covering
Bare cable
Cable with anti-corrosion covering
Bare cable
Cable with anti-corrosion covering
mm2
mm
mm
A
A
kg/km
kg/km
Light duty
2×1.0
2×1.5
2×2.5
2×4.0
5.1
5.7
6.6
7.7
6.7
7.3
8.2
9.7
17
22
30
38
20
24
33
44
104
130
179
248
125
153
205
282
3×1.0
3×1.5
3×2.5
5.8
6.4
7.3
7.4
8.0
10.1
15
19
25
17
21
28
135
168
224
159
193
258
4×1.0
4×1.5
4×2.5
6.3
7.0
8.1
7.9
9.0
10.1
15
19
25
16
21
28
161
203
278
187
230
314
7×1.0
7×1.5
7×2.5
7.6
8.4
9.7
9.6
10.4
11.7
10
13
17
11
14
19
172
294
413
207
331
455
Heavy duty
1×1.5
1×2.5
1×4.0
1×6.0
1×10.0
1×16.0
1×25.0
1×35.0
1×50.0
1×70.0
1×95.0
1×120.0
1×150.0
1×185.0
1×240.0
1×300.0
1×400.0
4.9
5.3
5.9
6.4
7.3
8.3
9.6
10.7
12.1
13.7
15.4
16.8
18.4
20.4
23.3
26.2
30.6
6.5
6.9
7.5
8.0
9.3
10.3
11.6
12.7
14.1
15.7
17.8
19.2
20.8
23.2
26.1
-
-
30
39
51
63
81
107
139
168
207
251
300
344
388
434
483
795
948
33
43
56
69
90
119
154
187
230
279
333
382
431
482
537
883
1053
88
114
140
172
235
319
451
573
764
1018
1298
1576
1890
2323
3031
3832
5228
108
135
162
198
258
356
439
619
816
1076
1386
1674
1997
2468
3197
-
-
2×1.5
2×2.5
2×4.0
2×6.0
2×10.0
2×16.0
2×25.0
7.9
8.7
9.8
10.9
12.7
14.7
17.1
9.9
10.7
11.8
12.9
14.7
16.7
19.5
24
32
42
54
74
98
128
26
36
47
60
82
109
142
212
260
342
427
582
845
1138
243
298
385
474
636
907
1238
3×1.5
3×2.5
3×4.0
3×6.0
3×10.0
3×16.0
3×25.0
8.3
9.3
10.4
11.5
13.6
15.6
18.2
10.3
11.3
12.4
13.5
15.6
18.0
20.6
20
27
36
46
62
83
108
22
30
40
51
69
92
120
242
311
399
507
728
980
1370
274
352
444
556
786
1069
1476
4×1.5
4×2.5
4×4.0
4×6.0
4×10.0
4×16.0
4×25.0
9.1
10.1
11.4
12.7
14.8
17.3
20.1
11.1
12.1
13.4
14.7
16.8
19.7
22.9
21
27
36
46
61
80
104
23
30
40
51
68
89
116
298
367
472
623
861
1275
1766
333
411
521
677
923
1376
1909
7×1.5
7×2.5
10.8
12.1
12.8
14.1
14
19
16
21
409
562
455
614
