Skycom Low Price Optical Power Meter

Nanjing Tianxingtong Electronic Technology Co., Ltd.

Application：Communication, Art, Sensor, Medicine, Probe
Connection Structure：FC,PC (or Customize)
Core：Sm mm
Certification：CE, ISO9001
Brand：Skycom
Wave Lengths：850 to 1625nm

Base Info

Model NO.：T-OP300-Serices
Transport Package：Carton
Specification：160mm *75mm * 32mm
Trademark：SKYCOM
Origin：China
HS Code：9031801000
Production Capacity：1500,Month

Description

AA * 2 batteries or AC/DC power supply adapter* at 20±3ºC, CW, with FC connector, -10dBm,
For 850nm, the Min. Power measurement: -60dBm@OP300T, -40dBm@OP300C

GENERAL SPECIFICATIONS

Size(HWD)	160mm 75mm 32mm
Weight	about 180g
Storage Temperature	-20 -- +60 ºC, < 90%RH
Operating Temperature	-10 -- +50 ºC, < 90%RH

ACCESSORIES

Standard	Optional
Carrying bag*1	SC interchangeable connector*1
Calibration Certificate*1	ST interchangeable connector*1
User′s manual*1	FC male to LC female adapter*1
	AC/DC adapter*1
