304 Stainless Steel Cable Socks, Cable Support Grips
HarshMet Material Solutions Ltd.- Type：Closed Mesh
- Certification：CE, RoHS, CCC, ISO
- Customized：Customized
- Condition：New
- Feature：Antirust
- Transport Package：Standard Package
Base Info
- Model NO.：HG Series
- Specification：304 Stainless Steel
- Trademark：HarshMet
- Origin：China
- HS Code：851770900
- Production Capacity：50000PCS Per Month
Description
Basic Info.
Model NO. HG Series Specification 304 Stainless Steel Trademark HarshMet Origin China HS Code 851770900 Production Capacity 50000PCS Per MonthProduct Description
Wire Mesh Cable Socks/Bus Drop Cable Support Grips
- Bus drop grips are woven of galvanized steel/304 Stainless Steel wire
- Relieve any direct tension from the critical connection and absorb vibration and flexing
- Offered with either the single eye or locking bale attachment
- Bus drop grips are used as cable support from bus duct
- Optional bus drop safety spring can be used with single eye type of disassembling draw bar from coll, placing through eye loop and replacing draw bar
- Single eye for use when cable is vertical and for applications where cable bends
- Locking bale attachment fits around beam or pipe and can be locked in place
| Part Number | Cable Diameter | Bale Length | Mesh Length | Approx Break Strength |
| HG-22 | 0.22-0.32"(5.6-8.1mm) | 9"(228.6mm) | 3.5"(88.9mm) | 1100 lbs. |
| HG-30 | 0.30-0.43"(7.6-10.9mm) | 9"(228.6mm) | 4.5"(114.3mm) | 1100 lbs. |
| HG-41 | 0.41-0.56"(10.4-14.2mm) | 9"(228.6mm) | 5.0"(127.0mm) | 1100 lbs. |
| HG-53 | 0.53-0.73"(13.5-18.5mm) | 9"(228.6mm) | 6.5"(165.1mm) | 1100 lbs. |
| HG-70 | 0.70-0.85"(17.8-21.6mm) | 9"(228.6mm) | 8.5"(215.9mm) | 1900 lbs. |
| HG-82 | 0.82-1.00"(20.8-25.4mm) | 9"(228.6mm) | 8.5"(215.9mm) | 1900 lbs. |
| HG-96 | 0.96-1.25"(24.4-31.8mm) | 9"(228.6mm) | 11.0"(279.4mm) | 1900 lbs. |
