3/8" 5/8" 7/8" RF Feeder Cable 1/2"
SHG COMMUNICATION TECHNOLOGY (HANGZHOU) LTD.- Application：RF Cable
- Conductor Material：Copper
- Cover Material：PVC
- Type：1,2", 3,8", 5,8", 7,8"
- Certification：CE, ISO, RoHS, CCC, UL, VDE, Reach
- RF：1,2"
Base Info
- Model NO.：1,2"
- Transport Package：100m, 305m, 500m, 1000m Wooden , Plastic Reel
- Specification：CE, RoHS, ISO9001, UL, ETL
- Trademark：OEM
- Origin：China
- HS Code：85442000
- Production Capacity：20000km Per Month
Description
| Model |
Characteristic Impedance (Ohm) |
Inner Conductor (mm) |
Insulation (mm) |
Outer Conductor (mm) |
Outer Sheath (mm) |
Attenuation at 900MHz (dB/100m) |
Attenuation at 1800MHz (dB/100m) |
|
1/4" SF |
50 |
1.90 |
5.00 |
6.40 |
7.60 |
18.40 |
27.10 |
|
1/4" |
50 |
2.60 |
6.00 |
7.70 |
8.90 |
13.10 |
19.10 |
|
3/8" SF |
50 |
2.60 |
7.00 |
9.00 |
10.20 |
13.50 |
19.70 |
|
3/8" |
50 |
3.10 |
8.00 |
9.50 |
11.10 |
10.90 |
16.00 |
|
1/2" SF |
50 |
3.55 |
9.00 |
12.00 |
13.70 |
10.00 |
14.50 |
|
1/2" |
50 |
4.80 |
12.00 |
13.90 |
16.00 |
7.15 |
10.52 |
|
5/8" |
50 |
7.00 |
17.00 |
19.70 |
22.00 |
5.07 |
7.54 |
|
7/8" F |
50 |
9.40 |
22.00 |
24.90 |
27.50 |
4.05 |
6.03 |
|
7/8" SF |
50 |
9.40 |
22.00 |
24.90 |
27.50 |
4.30 |
6.30 |
|
7/8" |
50 |
9.00 |
22.00 |
24.90 |
27.50 |
3.87 |
5.84 |
|
7/8" Low Loss |
50 |
9.45 |
23.00 |
25.40 |
28.00 |
3.68 |
5.45 |
|
1-1/4" |
50 |
13.10 |
32.00 |
35.80 |
39.00 |
2.82 |
4.27 |
|
1-5/8" |
50 |
17.30 |
42.00 |
46.50 |
50.00 |
2.41 |
