- Model NO.：Warmmat
- Outer Insulation：Fluoropolymer or PVC
- Cold Lead：2-Wire 16 AWG Plus Ground Braid; 10FT (3m) Length
- HS Code：8516800000
| Cable Construction: | Twin conductor |
| Rated Voltage: | 120V,240V |
| Output: | 12W/ft2 (130W/m2)±10% |
| Cable spacing: | 3" (76.2mm) |
| Cable Diameter: | 1/8"-1/6" (3.2mm-4.2mm) |
| Conductor Insulation: | Fluoropolymer |
| Outer Insulation: | Fluoropolymer or PVC |
| Max. Ambient Temp.: | 85ºF(30ºC) |
| Min. Installation Temp.: | 40ºF(5ºC) |
| Cold lead | 10ft (3m) length |
Ordering information :| 120V | Heated Area | Mat Dimensions | Watts (12W/sq.ft.) | Amps | ohms |
| Catalog Number | sq.ft. | m2 | in.*ft. | m*m |
| WarmMat-010-1 | 10 | 0.93 | 20*6.1 | 0.5*1.9 | 120 | 1.0 | 120.0 |
| WarmMat-015-1 | 15 | 1.39 | 20*9.1 | 0.5*2.8 | 180 | 1.5 | 80.0 |
| WarmMat-020-1 | 20 | 1.86 | 20*12.2 | 0.5*3.7 | 240 | 2.0 | 60.0 |
| WarmMat-025-1 | 25 | 2.32 | 20*15.2 | 0.5*4.6 | 300 | 2.5 | 48.0 |
| WarmMat-030-1 | 30 | 2.79 | 20*18.3 | 0.5*5.6 | 360 | 3.0 | 40.0 |
| WarmMat-035-1 | 35 | 3.25 | 20*21.3 | 0.5*6.5 | 420 | 3.5 | 34.3 |
| WarmMat-040-1 | 40 | 3.72 | 20*24.4 | 0.5*7.4 | 480 | 4.0 | 30.0 |
| WarmMat-050-1 | 50 | 4.65 | 20*30.5 | 0.5*9.3 | 600 | 5.0 | 24.0 |
| WarmMat-060-1 | 60 | 5.57 | 20*36.6 | 0.5*11.1 | 720 | 6.0 | 20.0 |
| WarmMat-070-1 | 70 | 6.50 | 20*42.7 | 0.5*13.0 | 840 | 7.0 | 17.1 |
| WarmMat-080-1 | 80 | 7.43 | 20*48.8 | 0.5*14.9 | 960 | 8.0 | 15.0 |
| WarmMat-090-1 | 90 | 8.36 | 20*54.9 | 0.5*16.7 | 1080 | 9.0 | 13.3 |
| WarmMat-100-1 | 100 | 9.29 | 20*61.0 | 0.5*18.6 | 1200 | 10.0 | 12.0 |
| 240V | Heated Area | Mat Dimensions | Watts (12W/sq.ft.) | Amps | ohms |
| Catalog Number | sq.ft. | m2 | in.*ft. | m*m |
| WarmMat-020-2 | 20 | 1.86 | 20*12.2 | 0.5*3.7 | 240 | 1.0 | 240.0 |
| WarmMat-030-2 | 30 | 2.79 | 20*18.3 | 0.5*5.6 | 360 | 1.5 | 160.0 |
| WarmMat-035-2 | 35 | 3.25 | 20*21.3 | 0.5*6.5 | 420 | 1.8 | 137.1 |
| WarmMat-040-2 | 40 | 3.72 | 20*24.4 | 0.5*7.4 | 480 | 2.0 | 120.0 |
| WarmMat-050-2 | 50 | 4.65 | 20*30.5 | 0.5*9.3 | 600 | 2.5 | 96.0 |
| WarmMat-060-2 | 60 | 5.57 | 20*36.6 | 0.5*11.1 | 720 | 3.0 | 80.0 |
| WarmMat-070-2 | 70 | 6.50 | 20*42.7 | 0.5*13.0 | 840 | 3.5 | 68.6 |
| WarmMat-080-2 | 80 | 7.43 | 20*48.8 | 0.5*14.9 | 960 | 4.0 | 60.0 |
| WarmMat-090-2 | 90 | 8.36 | 20*54.9 | 0.5*16.7 | 1080 | 4.5 | 53.3 |
| WarmMat-100-2 | 100 | 9.29 | 20*61.0 | 0.5*18.6 | 1200 | 5.0 | 48.0 |
| WarmMat-110-2 | 110 | 10.22 | 20*67.1 | 0.5*20.4 | 1320 | 5.5 | 43.6 |
| WarmMat-120-2 | 120 | 11.15 | 20*73.2 | 0.5*22.3 | 1440 | 6.0 | 40.0 |
| WarmMat-145-2 | 145 | 13.47 | 20*88.4 | 0.5*26.9 | 1740 | 7.3 | 33.1 |
| WarmMat-160-2 | 160 | 14.86 | 20*97.5 | 0.5*29.7 | 1920 | 8.0 | 30.0 |
Why Choose Jiahong :
22 years experience made us to be the biggest manufacturer of heating cable in Asia. The only one have CE UL ETL TUV CSA certificate in Aisa. And 6-year's supplier of homedepot ,GE ,Grainger.
Products include heating mat ,heating cable ,thermostat and self regulating heating cable , All products approved and 100% inspected.Only adopts high-quality raw materials, key materials imported from American, Japan and Germany . It made our products with excellent quality .Better than any other competitors in China .
25-year warranty for underfloor heating system, 10-year warranty for self-regulating heating system; Deal and solve any of your concerns at the earliest time
Besides, we have a new cable only 2mm thickness.
