Helukable Alternative Oil Resistant Ob-Bl-Paar-Cy PVC Connection Cable 900V

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：OB-BL-PAAR-CY Cable
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemOil Resistant OB-BL-PAAR-CY PVC Connection Cable 900VConductorCopper wire bare, finely strandedInsulationPVCWrappingFoilScreenBraided screen of tinned copper wires, approx. coverage 85%Outer sheathPVCOperating Voltage900 V Test Voltage2 kVTemperature RangeFlexible -10°C to +80°C
Fixed -30°C to +80°CMinimum Bending RadiusFlexible 10x Outer-Ø
Fixed 5x Outer-ØColorOptional

Properties

Resistant to: oil
The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquersApplicationUsed for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control. For explosion-endangered areas marked as intrinsically safe (blue) (ignition protection type -i-) flexible control or measurement cable for intrinsically safe systems in measurement and control technology. These systems are not earthed and have a separate power circuit. These cables are not suitable for burial in the ground. The screening guarantees an exact data transmission. EMC= Electromagnetic Compatibility; in order to optimise EMC properties, we recommend a double-sided and all-round large contact area of the copper braiding.
