UV Radiation Resistant Jz-604-Fcy Tc Tray PVC Connection Cable 600V

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：JZ-604-FCY TC TRAY Cable
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemUV Radiation Resistant JZ-604-FCY TC TRAY PVC Connection Cable 600VConductorCopper wire bare, finely strandedInsulationPVCWrappingFleeceScreenBraided screen of tinned copper wires, approx. coverage 85%Outer sheathPVCOperating Voltage600 V Test Voltage3 kVTemperature RangeFlexible -5°C to +90°C
Fixed -25°C to +90°CMinimum Bending RadiusFlexible 10x Outer-Ø
Fixed 4x Outer-ØColorOptional

Properties

Resistant to: oil, UV radiation (SUN RES)
For outdoor use
Direct burial (DIR BUR)
The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquersApplicationNFPA 79 compliant, flexible control and connection cable (up to 600 V) for machinery in tool and plant constuction; suitable for installation in dry, damp and wet environments as well as outdoors. For underground installation and for open, unprotected installation from the cable rack to machines and industrial plants. EMC= Electromagnetic Compatibility; in order to optimise EMC properties, we recommend a double-sided and allround large contact area of the copper braiding.
