75ohm Rg11 Coaxial Cable for HD TV Cabling Satellite
Hangzhou Spring Electronics Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Copper Clad Steel
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Material Shape：Round Wire
- Certification：ISO9001, CE, RoHS
- Transport Package：Carton
- Specification：6 rolls
- Trademark：OEM
- Origin：Made in China
- Production Capacity：2000km,Month
Description
Basic Info.
Material Shape Round Wire Certification ISO9001, CE, RoHS Transport Package Carton Specification 6 rolls Trademark OEM Origin Made in China Production Capacity 2000km/MonthProduct Description
Examples:
1) RG6 Coaxial Cable 75ohm Dual / Standard shield
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+6.90±0.05mm PVC Jacket
2) RG6 Coaxial Cable 75ohm Tri Shielded
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+Al Foil+6.9mm PVC Jacket
3) RG6 Coaxial Cable 75ohm Quad Shield
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid +Double Al Foil+ Al Wire braiding +7.5mm PVC Jacket
4) RG6 Coaxial Cable 75ohm With Messenger
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+6.90±0.05mm PVC Jacket+1.30+0.05mm Messenger
5)OEM
