• Model NO.：1-YY
• Material Shape：Round Wire
• Range of Application：Installation
• Certification：ISO9001, CCC
• Brand：Boan
• Rated Voltage：0.6,1 Kv
• Size：25-500 Mm2
• Class of Conductor：2
• Transport Package：Heated Steel-Wooden Drum,Steel Drum
• Specification：SGS
• Trademark：DingAn or OEM
• Origin：Jiangsu Yixing, China
• HS Code：8544492100
• Production Capacity：38000 Km,Year

Basic Info.

Model NO. 1-YY Material Shape Round Wire Range of Application Installation Certification ISO9001, CCC Brand Boan Rated Voltage 0.6/1 Kv Size 25-500 Mm2 Class of Conductor 2 Transport Package Heated Steel-Wooden Drum/Steel Drum Specification SGS Trademark DingAn or OEM Origin Jiangsu Yixing, China HS Code 8544492100 Production Capacity 38000 Km/Year

Product Description

1-YY
Installation single-core cables with Cu-conductor

Application:
For fixed installation, indoors and outdoors, in the ground and in concrete. The cables are resistant to UV radiation and to flame propagation according to IEC 60332-1.

Rated voltage: 0.6/1 kV
Test voltage: 4 kV
Maximal short-circuit temperature: 160
Operating cond. Temperature: 70
Min. Temperature for laying and manipulation with cables: -5
Color of insulation: HD 308 S2

Number of cores x cross-section	Shape of the conductor	Diameter appr.	Cable mass appr.	Radius of bend	Effect. resist. of conductors	Short circuit current-equiv.	Time heating constant	Current carrying cap. in air	Current carrying cap. in ground	Inductivity	Content Cu
(n x mm2)		(mm)	(kg/km)	(mm)	(/km)	(kA)	(s)	(A)	(A)	(mH/km)	(kg/km)
1x25	RMV	12	350	180	0,727	2,880	195	144	208	0,490	245
1x35	RMV	13	430	200	0,524	4,020	255	176	250	0,480	343
1x50	RMV	14	570	215	0,387	5,750	353	214	296	0,480	490
1x70	RMV	16	776	240	0,268	7,950	434	270	365	0,460	686
1x95	RMV	18	1050	270	0,193	10,925	523	334	438	0,460	931
1x120	RMV	19	1285	300	0,153	13,800	615	389	501	0,450	1176
1x150	RMV	21	1575	315	0,125	17,250	731	446	563	0,450	1470
1x185	RMV	24	1951	360	0,099	21,270	830	516	639	0,450	1813
1x240	RMV	26	2532	400	0,075	27,600	974	618	746	0,440	2352
1x300	RMV	29	3141	435	0,060	34,500	1150	711	845	0,440	2940
1x400	RMV	32	3974	490	0,047	41,200	1454	843	975	0,440	3920
1x500	RMV	36	5067	545	0,037	51,500	1634	995	1145	0,430	4900
