UL10602 Solid Copper Conductor 16AWG Thin Wall Frpe Insulated Extruted Electrical Hook up Wire

B&T (Zhangzhou) Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：for General Purpose Internal Wiring of Appliance
  • Conductor Material：Copper
  • Insulation Material：Frpe
  • Material Shape：Round Wire

Base Info

  • Model NO.：UL10602
  • Range of Application：Flame Retardant
  • Certification：ISO9001, UL, RoHS, Reach
  • Brand：B&T
  • Rated Temperature：80 ºC
  • Rated Voltage：12-14V
  • According to：UL Subject758, UL1581, C22.2
  • Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
  • Performance：for General Purpose Internal Wiring of Appliance
  • Conductor：Stranded, Tinned or Bare Copper Conductor
  • Capacity：300,000km Annual
  • Color：Could Be Customized Color
  • Delivery Time：7-15days
  • Package：Coil or Spool Packing
  • Transport Package：610feet in Roll
  • Specification：2pin 20 AWG 2 Conductors
  • Trademark：B&T
  • Origin：Xiamen, Fujian
  • HS Code：8544492100
  • Production Capacity：300, 000km

Description

Rated Temperature80ºCRated Voltage300VStandardMaximum Resistance at 20ºC
Ω/kmAWGNo./mmDia.
mmNom. Thick.
mmNom.Dia.
mm307/0.10.300.260.82354287/0.1270.380.260.90223267/0.160.480.261.001392411/0.160.610.271.1588.92217/0.160.760.261.2857.52026/0.160.940.261.4634.61841/0.161.180.261.7023.31626/0.2541.490.262.0215.1
