Nyy Assembly Rg58/Rg59/RG6 Coaxial Cable with TV F BNC Connector Quad-Shield RG6 Coaxial Network Communication Wire Cable Power Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Home Wire
- Voltage：Low and Medium Voltage Cable
- Insulation Material：PVC
- Sheath Material：PVC
- Material Shape：Round Wire
- Wire Core Material：Bare Copper Wire
Base Info
- Model NO.：Power Cables
- Certification：ISO, CCC, CE
- Model：RG6,U
- Brand：Feng Da
- Colour：Red,Green,Blue,Black,White,as Request
- OEM/ODM：Yes
- Flame Test：Yes
- Transport Package：Rolls or According to Customer′s Request
- Trademark：feiya
- Origin：Tianjin, China
- HS Code：8544422900
Description
Features:
- The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers
- H-outer sheath = halogen-free material (HM2)
- RG-Coaxial types are in accordance with US-Military specifications MIL-C-17.
- RG/U: R=Radio, G=Guide, U=Utility
- FRNC = Flame Retardant Non-Corrosive
Coaxial cables are used in high frequency transmission, especially for transmitters and receivers, computers, radio and TV transmissions. The varied mechanical, thermal and electronic properties of Coaxial cables mean that they can be used up into the GHz levels, as per cable type.
Coaxial cables
| Inner conductor diameter mm | 7 x 0,4 Tinned copper | 19 x 0,2 Tinned copper | 1 x 0,6 Steel/copper, bare | 1 x 0,6 Steel/copper, bare | 1 x 0,6 Steel/copper, bare | 7 x 0,8 Copper, bare | 7 x 0,8 Silvered copper |
| Insulation Ø mm | 7,3 PE | 2,95 PE | 3,7 PE | 3,7 PE,hollow | 3,7 PE,hollow | 7,24 E | 7,24 PE |
| Outer conductor | Braid | Braid | Braid | Braid | 2 braids | Braid | 2 braids |
| Copper, bare | Tinned copper | Copper, bare | Copper, bare | Copper, bare,Tinned copper | Copper,bare | 2xsilvered copper | |
| Outer sheath | HM2 | HM2 | HM2 | HM2 | HM2 | HM2 | HM2 |
| Min. bending radius approx. mm | 50 | 25 | 30 | 30 | 30 | 50 | 50 |
| Temperature range °C | 35 to +80 | 35 to +80 | -35 to +80 | 35 to +80 | 50 to +70 | 35 to +80 | -35 to +80 |
| Copper weight kg/km | 58,0 | 29,0 | 28,0 | 28,0 | 48,0 | 85,0 | 120,0 |
| Outer Ø approx. mm | 10,3 | 5,4 | 6,4 | 6,4 | 6,9 | 10,3 | 10,8 |
| Weight approx. kg / km | 144 | 38 | 57 | 54 | 64 | 155 | 203 |
FAQ
Q: Is small order less than 100pcs accepted?
A: Yes, please contact with us, we will send you link for small order.
Q: How to ship the order? Is it Safe?
A: Heavy goods are transported by container, sea or air to the designated port. For small packages, recommend sending by express, such as DHL, FEDEX, UPS, TNT, EMS, ect which are door to door service.
Q: What is your terms of payment?
A: Payment terms are flexible, T/T, Paypal, L/C, D/A, D/P, Western Union, Money Gram etc. And you can pay on Alibaba with your credit card.
Q: What is your working time?
A: From 8AM to 8PM Monday noon to Sunday noon. Please feel free to contact us. Our sales staff is on a rotation basis. The customer service is available 24 hours a day, checking customer emails, responding to customer questions and messages, and providing the most convenient service for each customer.
