34.4 75.5 148 Almelec Conductor-AAAC Conductor
YIFANG ELECTRIC GROUP INC.- Application：Construction, Overhead, Industrial, Power Station
- Voltage：High Voltage Cable
- Current：DC & AC
- Insulation Material：Bare
- Sheath Material：None
- Material Shape：Round Wire
Base Info
- Model NO.：Almelec Conductor
- Wire Core Material：Bare Conductor
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：Bare Conductor
- Brand：Yifang
- Transport Package：Drum
- Specification：34.4mm2 54.6mm2 75.5mm2 117mm2 148mm2
- Trademark：Yifang cable
- Origin：Henan Zhengzhou
- HS Code：7614900000
- Production Capacity：500ton Per Month
Description
Basic Info.
Model NO. Almelec Conductor Wire Core Material Bare Conductor Certification ISO, CCC, CE, RoHS, UL, VDE Model Bare Conductor Brand Yifang Transport Package Drum Specification 34.4mm2 54.6mm2 75.5mm2 117mm2 148mm2 Trademark Yifang cable Origin Henan Zhengzhou HS Code 7614900000 Production Capacity 500ton Per MonthProduct Description
34.4 75.5 148 Almelec Conductor-AAAC ConductorAAAC Conductor (All Aluminium Alloy Conductor)
1. AAAC Conductor standard available such as IEC61089, ASTM B-399, BS3242, CSA60104, DIN 48201, CSA 60104, etc.
2. AAAC and AACSR are widely used in power transmission lines with various voltage levels, and also used in power lines across great rivers, heavy ice area, etc. They are of excellent advantages of high strength, large current carrying capacity and good catenaries property as well as wear-resistance, anti-crush and corrosion-proof with simple structure, convenient installation and maintenance, low cost for the line, large transmission capacity.
3. Certificate available: ISO, CE, SGS, SONCAP, BV, COC etc
For further information, pls contact us.NFC34-125 standrad:
| Nominal areamm2 | No. of wire and wire diamm |
| 22 | 7x2.0 |
| 34.4 | 7x2.5 |
| 54.6 | 7x3.15 |
| 75.6 | 19x2.25 |
| 117 | 19x2.8 |
| 148 | 19x3.15 |
| 181.6 | 37x2.5 |
| 228 | 37x2.8 |
| 288 | 37x3.15 |
| 366 | 37x3.55 |
| 570 | 61x3.45 |
