0.6/1kv Low Voltage N2xcy Power and Signal Cable 4X2X0.5mm2

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Installation
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：XLPE

Base Info

  • Model NO.：N2XCY
  • Material Shape：Round Wire
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemN2XCY Power and Signal CableConductorCopper (as client's required)InsulationXLPE (as client's required)Outer SheathPVC (as client's required)Operating Voltage0.6/1KVTest voltage 4000VTemperature RangeFlexible installation: -5 °C up to +50°C
Fixed installed: -20°C up to +90°CColorOptionalCertificationCE TUVApplicationApplication Distribution and signal power cable for static application in ground, in water, within facilities, in cable canals, in concrete, in conditions where there is a danger of possible mechanical damages, but where the cable is not exposed either to systematic mechanical stress or heavier tensile strain. Concentric conductor can be used as neutral, protective or earth connection, and in conditions where it is exposed to danger of damages caused by digging, it acts as protection against contact voltage, in case of rough insulation damage. Used in transformer stations, industrial plants, metropolitan networks and in other electric plants where heavier current and thermal loads are expected (operating temperature of conductor up to 90 °C).
