• Model NO.：26,35 kV XLPE Power Cable
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE, UL
• Model：YJV
• Certificate：ISO;Ce;UL;Kema
• Transport Package：Wood Packing by Sea
• Trademark：Yifang
• Origin：China
• HS Code：8544601200
• Production Capacity：100km Per Week

Basic Info.

Model NO. 26/35 kV XLPE Power Cable Wire Core Material Bare Copper Wire Certification ISO, CCC, CE, UL Model YJV Certificate ISO;Ce;UL;Kema Transport Package Wood Packing by Sea Trademark Yifang Origin China HS Code 8544601200 Production Capacity 100km Per Week

Product Description

NUMBER OF CORES:

1 or 3 cores



CONSTRUCTION:  Cu(or AL) /XLPE/CTS/PVC/STA or SWA/PVC Cable

1). Conductor: Aluminum, Copper, Class 2 according to IEC60228
2). semiconductive conductor screen
3). CTS: Copper Tape Screen
4). Insulation: XLPE or TR-XLPE (Cross-Linked Polyethylene)
5). semiconductive insulation screen
6). metallic screen(Copper wire or Copper tape Screen)
7). PVC bedding
8). Armour: Galvanized steel wire Armor(SWA ) or Galvanized tape Armor(STA )
9). PVC outer sheath
10).Sheath Color: Black or Colors



SECTIONAL AREA:

25 mm2  , 35 mm2 , 50 mm2  ,70 mm2  , 95 mm2  ,120 mm2  ,150 mm2 ,185 mm2  ,240 mm2 ,300 mm2  400 mm2 500 mm2 630 mm2 800 mm2



TECHNICAL DATA:

Rated Voltage (Uo/U)(Um)	26/35KV
Test Voltage	63kV
Conductor	Class 2 Stranded Copper or Aluminum Conductors for Single Core and three-Core Cables
Inner Semi-Conductive Layer	Semi-conductive material
Insulation	XLPE (Cross-Linked Polyethylene)
Outer Semi-Conductive Layer	Semi-conductive material
Insulation Screen	Semi-conductive XLPE (Cross-Linked Polyethylene)
Screen	Copper wires or Copper tape
Armour	Single core: AWA (Aluminium Wire Armoured)Multi-core: SWA (Steel Wire Armoured)
Sheath	PVC (Polyvinyl Chloride)
Temperature Rating	-20°C to +70°C
Minimum Bending Radius	15 x overall diameter
