600V Kynar/Hmwpe Cathodic Protection Cable

YIFANG ELECTRIC GROUP INC.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Cathodic Protec
  • Conductor Material：Copper
  • Insulation Material：Hmwpe,PVDF,Kynar
  • Certification：ISO9001, CE, UL, CCC, RoHS, VDE

Base Info

  • Colour：Black and Red
  • Transport Package：Coil, Drum, Pallet
  • Specification：up to 400mm2
  • Trademark：Yifang cable
  • Origin：Zhengzhou, Henan, China
  • Production Capacity：500km Per Month

Description

TypeProduct NameCPVVCopper conductor PVC insulated and sheathed cathodic protection cable
(Cu/PVC/PVC)CPYCopper conductor HDPE insulated cathodic protection cable
(Cu/HMWPE)CPFYCopper conductor fluorine plastic insulated HDPE sheathed cathodic protection cable
(Cu/PVDM/HMWPE; Cu/KYNAR/HMWPE)CPFY33Copper conductor fluorine plastic insulated fine-steel-wire-armored HDPE sheathed cathodic protection cable
(Cu/PVDM/SWA/HMWPE; Cu/KYNAR/SWA/HMWPE)
4. Characteristics
   1) Rated voltage: DC600V
   2) Long-term permissible working temperature of cable conductor:
       PVC insulated cable: 70oC
       HMWPE insulated cable: 90oC
       PVDF/KYNAR insulated cable: 135oC
   3) The layout temperature of cable shall not be lower than -20oC
   4) The bending radius: 20D (D is outer diameter cable )
