Motor and Servo Cables for Fixed or Not Constantly Movements 0.6/1 Kv

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PP
  • Material Shape：Round Wire

Base Info

  • Model NO.：Motor And Servo Cables
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemMotor And Servo Cables For Fixed Or Not Constantly Movements 0.6/1 kVConductorBare copperInsulationHalogen-free PPScreenBraided screen of tinned copper wires, approx. coverage 85%WrappingFleeceOuter sheathPVCOperating Voltage600/1000 V Test Voltage4 kVTemperature RangeFlexible -0°C to +60°C
Fixed -20°C to +80°CMinimum Bending RadiusFlexible 15x Outer-Ø
Fixed 5x Outer-ØColorOptionalApplicationThe combination of supply cores with the control cores for the braking function and the thermal protection in these cables is ideal. Precision servomotors, as used today in many areas of highly-automated manufacturing processes, call for high-quality, reliable and long-lasting cables. These requirements are met to a high degree by these cables. The cables have an additional overall screen to ensure EMC compatibility, i.e. for protection against electromagnetic interference. Production is based on the specifications of established manufacturers of servo-drives and controls, as well as on various VDE, UL and CSA standards.
Applications include machine, plant and robot construction, automation, drive, control and production engineering.
Attractive for export-oriented mechanical and system engineering.
