K J Thermocouple Extension Wire or Cable
Jiangyin Senphus Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Testing Temperature
- Conductor Material：Nicr-Nial
- Sheath Material：PVC
- Insulation Material：Silicone Rubber
Base Info
- Model NO.：thermocouple wire
- Material Shape：Round Wire
- Certification：ISO9001
- Brand：Reou
- Thermocouple Wire Diameter：7*0.52mm, 18AWG, 16AWG, etc
- Thermocouple Wire Insulation：FEP, Silicone Rubber, PVC, XLPE, etc
- Thermocouple Wire Jacket：Fiberglass
- Thermocouple Wire Color：Standard, or You Customize
- Thermocouple Wire Length：1000m, 2000m, or 5000m Per Spool
- Transport Package：Coil+Sealant+Carton
- Specification：RoHS
- Trademark：SENPHUS
- Origin：China
- Production Capacity：10000000000m
Description
Name and code of alloy wiresDiameter of wires mm Maximum temperature º C Anode Cathode Name Code Name Code Long-time Short-time PtRh30 BP PtRh6 BN Φ 0.5 1600 1800 PtRh13 RP Pt RN Φ 0.5 1400 1600 PtRh10 SP Pt SN Φ 0.5 1300 1600 PtRh10 KP NiSi3 KN Φ 0.3 700 800 Φ 0.5 800 900 Φ 0.8 Φ 1.0 900 1000 Φ 1.2 Φ 1.6 1000 1100 Φ 2.0 Φ 2.5 1100 1200 NiCr-NiSi NP NiSi4 NN Φ 3.2 1200 1300 NiCr-CuNi (constantan) EP CuNi45 EN Φ 0.3 Φ 0.5 350 450 Φ 0.8 Φ 1.0 Φ 1.2 450 550 Φ 1.6 Φ 2.0 550 650 Φ 2.5 650 750 Φ 3.2 750 900 Fe-CuNi (constantan) JP CuNi45 JN Φ 0.3 Φ 0.5 300 400 Φ 0.8 Φ 1.0 Φ 1.2 400 500 Φ 1.6 Φ 2.0 500 600 Φ 2.5 Φ 3.2 600 750 Cu-CuNi (constantan) TP CuNi45 TN Φ 0.2 Φ 0.3 150 200 Φ 0.5 Φ 0.8 200 250 Φ 1.0 Φ 1.2 250 300 Φ 1.6 Φ 2.0 300 350
