Single Conductor 230V Under-Tile Electrical Space Heating System

Wuhu Jiahong New Material Co., Ltd.
  • Cable Construction：Singe Conductor with Screen
  • Rated Voltage：230V
  • Output：100W,M2 &150W,M2
  • Cable Spacing：100mm & 66.7mm
  • Cable Diameter：2.6mm
  • Conductor Insulation：Fluoropolymer

Base Info

  • Model NO.：minimatS
  • Outer Insulation：PVC
  • Cold Lead：Two Wires Plus Ground Braid; 2.5m Length Each
  • Production Capacity：17000PCS Per Day

Description

Basic Info.

Model NO. minimatS Outer Insulation PVC Cold Lead Two Wires Plus Ground Braid; 2.5m Length Each Production Capacity 17000PCS Per Day

Product Description

MinimatS floor warming mat system
combine the highest comfort levels with maximum energy efficiency.It's a proven technology which is safe,reliable and energy efficient.
Double point connection--Single conducor with screen--Very thin,only 2.6mm--Safety approved for wet locations--Flexible installation--Durable construction---25 years limited warranty against manufacturing defects
The MinimatS floor warming system includes a yellow heating cable woven into an adhesive-backed red fiberglass mesh that allows for simple roll-out installation without worrying about cable spacing.

Single Conductor 230V Under-Tile Electrical Space Heating System
WHY JIAHONG

Company
1, Reliable: Over 20-year production and sales experience in Electric heating cable
2, Strong R&D ability: a team of 10+ professional engineers with 20-year experience
3, Passed ISO9001 by France BV Company
4, With 1200M² warehouse to stock for you to shorten lead time
5, 25 million USD export value in 2014, expected 20%-30% growth annually

Product
     1, Only adopts high-quality raw materials, key materials imported from American, Japan and Germany
     2, Strict QC system: products 100% inspected
     3, Approvals: UL, cULus, CSA, cETLus, TUV, CE, EAC, ATEX, IECEX, RoHS, EMF
     4, Approved by world famous companies: General Electric, Grainger industrial etc.

Service (Superior customer services)
     1, Pre-sale: professional and responsible sales team provides full products solutions
     2, Sale: whole process traceable
     3, After-sale: 25-year warranty for underfloor heating system, 10-year warranty for self-regulating heating system; Deal and solve any of your concerns at the earliest

Others
     1, Provide whole heating solution: offer full range of products and accept customized products
     2, As a manufacturer, Jiahong provides competitive price, faster delivery and OEM solution
      3, Convenient shipment: Close to Shanghai and Ningbo port.
